CELLFAST C. Snake General Stack ZBR 16.0 50m Multicore Audio Cable

The CELLFAST C. Snake General Stack ZBR 16.0 50m is a professional-grade multicore audio cable designed for stage and studio applications. With 16 balanced channels and a robust 50-meter length, it provides reliable signal transmission for complex audio setups. The cable features individual spiral copper shielding per channel to minimize crosstalk and interference, ensuring pristine audio quality. Its durable PVC jacket and 16.0 mm outer diameter offer excellent protection for demanding live environments.

Advantages

High-quality bare copper conductors with 2 x 0.22 mm² cross-section per channel ensure low resistance and clear signal transfer. The spiral copper shield per channel provides effective EMI/RFI rejection. The cable is flexible yet sturdy, making it easy to route on stage or in the studio.

Suitable for

• Professional audio multicore snakes for live sound
• Studio recording and broadcast applications
• Connecting mixing consoles to stage boxes
• Long-distance analog audio transmission

Key specifications

• Cable Type: Multicore Audio Cable
• Number of Channels: 16
• Cable Length: 50 m
• Conductor Cross-Section: 2 x 0.22 mm² (AWG 24) per channel
• Conductor Material: Bare Copper
• Shielding: Spiral Copper Shield per channel
• Jacket Material: PVC
• Outer Diameter: 16.0 mm
• Capacitance (Cond./Cond.): 110 pF/m
• Conductor Resistance: 85 Ohm/km
• Operating Temperature: -20°C to +70°C
• Colour: Black

Recommendations

For optimal performance, use with professional XLR connectors and ensure proper cable management to avoid kinking. Suitable for both permanent installations and touring applications.
