Cable DELOCK 83632 — USB 2.0, USB-C to Micro-USB B, 10 m, Black

DELOCK 83632 is a 10 m USB data cable with a USB-C connector on one end and a Micro-USB B connector on the other. It is designed to provide extended-reach connections for data transfer and device charging where standard cables are too short. The cable supports USB signalling and is finished in black.

Advantages

This cable combines an active optical hybrid construction with copper components to maintain signal integrity over a long 10 m run while remaining thinner and lighter than traditional all-copper cables. The Micro-USB B connector uses screws to secure the connection and reduce the risk of accidental unplugging. The cable is downwards compatible with USB 2.0 devices and supports higher-speed USB 10 Gbps signalling when used with compatible hosts and devices.

Suitable for

• Connecting mobile devices with Micro-USB B ports to hosts with USB-C ports over extended distances
• Data transfer between peripherals and PCs where a longer reach is required
• Charging compatible devices up to the supported output current over longer cable runs

Key specifications

• Connector 1: USB Type-C (straight male)
• Connector 2: Micro-USB B (straight male) with screws, screw distance 18 mm, screw type M2 x 2
• USB version: compatible with USB 2.0 signals; supports USB 10 Gbps signalling on compatible devices
• Cable length: 10 m
• Active optical hybrid: fiber/copper hybrid construction
• Data transfer rate: up to 10 Gbps when connected to compatible USB 10 Gbps host and device
• Output current: up to 900 mA
• Cable diameter: approximately 4.8 mm; smallest bending radius approximately 20 mm
• Cable jacket material: LSZH
• Operating temperature range: -10 °C to 50 °C
• Colour: Black

How to use

Plug the USB-C straight male connector into the host device (PC, laptop or other compatible USB-C host). Insert the Micro-USB B straight male connector into the target device, and tighten the connector screws if required to secure the connection. Ensure the correct orientation of both connectors before insertion. For highest data rates, use with host and device that support USB 10 Gbps signalling; for USB 2.0 devices standard speeds will apply. Avoid sharp bends and maintain the specified minimum bending radius to preserve cable integrity.

Recommendations

Place the cable so it is not under tension and avoid kinking; keep the cable within the operating temperature range. When using higher data rates, ensure both connected devices explicitly support USB 10 Gbps signalling. Use the connector screws on the Micro-USB B side to prevent accidental disconnection in installations where movement or vibration may occur.
