Cable combiner Axing SWE 40-01

The Axing SWE 40-01 cable combiner merges terrestrial (TV/FM) signals into a satellite distribution system that uses a Quad LNB with integrated multiswitch. Designed for the frequency range 950–2200 MHz, the grey unit with F-female (F-Buchse) connectors provides a compact and compatible solution for feeding additional signals into SAT installations.

Advantages

The cable combiner supports a broad frequency range (950–2200 MHz), ensuring compatibility with common satellite and terrestrial IF signals. F-female connectors offer easy connection to coaxial cables and SAT equipment, while the compact grey housing simplifies installation in existing setups. The device enables combining without altering the LNB, making it suitable for retrofitting and expanding systems.

Suitable for

Key specifications

How to use

Connect the terrestrial signal cable (TV/FM) to the designated F-female input of the combiner and connect the combiner output to the SAT system input that serves the Quad-LNB/multiswitch. Ensure all coaxial connections are tightened securely and that the system is powered down during installation. After connections are made, power the SAT distribution and verify signal reception on connected receivers.

Recommendations

Use the combiner only within the specified 950–2200 MHz range and with properly shielded coaxial cables. Avoid exposing the unit to moisture and install it in an accessible, ventilated location. If signal levels are weak after installation, check cable quality, connector integrity and LNB/multiswitch settings.
