BlueOptics SFP28 25/10G-LR-SFP10KM-BO fiber optic transceiver 25 Gbit/s 1310 nm LC singlemode 10 km

The BlueOptics 25/10G-LR-SFP10KM-BO is an SFP28 fiber optic transceiver module designed for 10G and 25GBASE-LR links over singlemode fiber. It uses an LC Duplex interface and operates at a wavelength of 1310 nm to support data rates up to 25 Gbit/s with a reach of up to 10 km. The module includes Digital Diagnostics Monitoring (DDM/DOM) compliant with MSA SFF-8472 for real-time monitoring of voltage, temperature, laser bias current and optical power.

Advantages

This BlueOptics SFP28 module follows MSA standards and is manufactured with components from established suppliers to ensure consistent compatibility, long service life and stable performance. It supports both 10G and 25G transmission modes, offers DDM for remote diagnostics, and is built for continuous operation with a high MTBF rating.

Suitable for

Key specifications

How to use

Insert the SFP28 module into a compatible SFP28 slot on your Extreme Networks-compatible switch, router or other networking device. Connect LC Duplex singlemode fiber patch cables to the module and to the corresponding remote transceiver or patch panel. Ensure the host device supports 10G/25GBASE-LR and, if you need diagnostic data, that the device exposes DDM/DOM information. After installation, verify link status and correct speed/duplex settings in the host equipment.

Recommendations

Use certified singlemode LC Duplex patch cables and test the optical link after installation. For long-term availability, keep spare modules in inventory and monitor DDM parameters to detect degradations early.
