SFP+ transceiver CBO SFP-10G-ER-1310 10G 1310nm single‑mode optical module

The CBO SFP-10G-ER-1310 is a 10 Gbps SFP+ optical transceiver module designed for single-mode fiber applications using a 1310 nm wavelength. Intended for long-reach links, this SFP+ module delivers high-speed data transmission for network uplinks, metro connections and data centre interconnects. It conforms to standard SFP+ electrical and mechanical interfaces for compatibility with a wide range of switches and routers that accept SFP+ form-factor modules.

Advantages

This optical module provides a 10 Gbit/s data rate with a 1310 nm optical wavelength optimized for single-mode fiber, enabling extended transmission distances compared with multi-mode solutions. The SFP+ form factor ensures low power consumption and compact installation in network devices with SFP+ cages. Compliance with common SFP+ signalling and optical link parameters simplifies integration and replacement in existing infrastructures.

Suitable for

• Long-reach single-mode fiber links between buildings or within campus networks
• 10 Gbps uplinks for aggregation switches and core routers
• Data centre server-to-switch and switch-to-switch interconnects over single-mode fiber
• Metro Ethernet and carrier access links requiring 10G capacity

Key specifications

• Data rate: 10 Gbps
• Optical wavelength: 1310 nm
• Fiber type: single-mode fiber (SMF)
• Form factor: SFP+ (small form-factor pluggable)
• Typical reach: long-reach links suitable for campus and metro distances (dependent on fiber and system margin)
• Connector type: LC duplex compatible
• Electrical interface: SFI/SFP+ compatible
• Power consumption: low-power SFP+ class (device-specific values depend on operating conditions)

How to use

Install the SFP+ transceiver into an available SFP+ port on a compatible switch or router while the host port is powered down if recommended by the network equipment vendor. Once seated, connect LC duplex single-mode fiber patch cords to the module, observing correct transmit/receive orientation. After insertion and fiber connection, verify link status using the host device management interface and check for correct operating parameters such as link speed and optical power levels. Follow the network device vendor’s guidelines for hot-plugging support and module compatibility if required.

Recommendations

Use factory-cleaned LC connectors and follow proper fibre handling procedures to avoid contamination and signal degradation. Confirm device compatibility and supported transceiver lists in the switch or router documentation before deployment. For long-reach links, plan for appropriate optical power budget and dispersion considerations based on fiber type and link length.
