SFP Transceiver CBO AFCT-5760PZ 850nm multimode fiber, 550m reach

CBO AFCT-5760PZ 850nm multimode SFP transceiver is designed for short-range fiber optic connections. The module supports transmission over multimode fiber at 850 nm with a maximum reach of 550 meters, and fits standard SFP ports on switches, routers and media converters. It provides a plug-and-play solution for restoring or expanding fiber links in enterprise networks, campus backbones and data center access layers.

Advantages

The transceiver follows the SFP form factor for broad compatibility with network equipment that accepts standard SFP modules. Operating at 850 nm for multimode fiber allows reliable short-distance optical links while keeping installation straightforward. With a 550 m maximum reach, the module covers most building-to-building and intra-campus fiber runs without additional signal boosters. The plug-and-play design reduces deployment time and requires no special configuration on supported devices.

Suitable for

• Short-range multimode fiber connections in enterprise LANs
• Campus backbone and building interconnects
• Data center access links and top-of-rack connectivity
• Upgrading or replacing SFP fiber ports on switches and media converters

Key specifications

• Wavelength: 850 nm
• Fiber type: Multimode fiber (MMF)
• Maximum reach: 550 meters
• Form factor: Small Form-factor Pluggable (SFP)
• Data interface: Optical SFP compatible with standard SFP ports

How to use

Insert the SFP transceiver into an empty SFP slot on a compatible switch, router or media converter until it clicks into place. Connect multimode fiber cables (with matching LC connectors if required) between the transceiver and the remote device. Ensure both ends use multimode fiber and the connector types match. Power on the networking equipment and confirm link status through device LEDs or management interface. No additional software configuration is typically required for basic link operation.

Recommendations

For reliable performance, use OM1/OM2/OM3/OM4 multimode fiber rated for short-range 850 nm transmission and verify port compatibility of the host device. Avoid bending the fiber beyond manufacturer-recommended radii and keep connectors clean to minimize insertion loss. Use this module for links up to 550 m; for longer distances consider single-mode solutions or modules rated for extended reach.
