SFP+ Transceiver CBO 02311BJC 10Gbps 850nm Multimode Fiber

The BlueOptics SFP+ Transceiver CBO 02311BJC is a compact optical module that delivers 10Gbps data transmission over multimode fiber using an 850nm wavelength. Designed for short-range links, this SFP+ form-factor transceiver supports hot-swap installation and integrates with compatible 10G ports to provide optical uplinks for servers, switches and storage systems in data center and enterprise environments.

Advantages

This transceiver offers a standardized SFP+ interface for easy installation and replacement without powering down equipment. The 850nm multimode design is optimized for high-speed short-range connectivity and supports reliable performance in densely cabled environments. Its compact size helps preserve port density on switches and network interface cards while maintaining low power consumption and stable optical signal quality.

Suitable for

• Short-range 10 Gigabit Ethernet links within data centers
• Server-to-switch and switch-to-switch uplinks
• Storage area network (SAN) interconnects over multimode fiber
• Patch panels and optical distribution frames with SFP+ ports

Key specifications

• Data rate: 10 Gbps
• Wavelength: 850 nm
• Fiber type: Multimode fiber (MMF)
• Form factor: SFP+
• Connector type: LC duplex
• Typical reach: short-range multimode links (OM2/OM3/OM4 dependent)
• Hot-pluggable: Yes
• Power consumption: low (SFP+ class)

How to use

Insert the SFP+ transceiver into a compatible 10G SFP+ slot on a switch, network interface card or storage device until it clicks into place. Connect LC duplex multimode fiber cables between devices, ensuring correct transmit/receive alignment. Monitor link status via device LEDs or management software and verify signal parameters in the equipment interface. To remove the module, disengage any locking mechanism and pull the module straight out while the system remains powered if supported.

Recommendations

For optimal performance, use multimode fiber rated for the intended reach (OM3/OM4 for extended short-range distances), keep fiber connectors clean, and confirm compatibility with host equipment. Avoid bending fiber beyond its minimum bend radius and follow standard electrostatic discharge precautions when handling the transceiver.
