BlueOptics SFP BO08C38S1 Compatible with Finisar FCLF-8520-3, 1.25 Gbps, 850 nm, 550 m, LC, Multimode

The BlueOptics SFP BO08C38S1 is a high-performance, cost-effective transceiver designed for Gigabit Ethernet applications. It is fully compatible with Finisar FCLF-8520-3 and meets MSA standards, ensuring seamless integration into existing network infrastructures. This SFP module operates at 1.25 Gbps over multimode fiber, utilizing 850 nm VCSEL technology to deliver reliable connectivity up to 550 meters.

Advantages

By choosing the BlueOptics BO08C38S1, you benefit from significant cost savings without compromising on quality or performance. The module is hot-pluggable, supports Digital Diagnostic Monitoring (DDM) for real-time performance tracking, and is built with a robust metal housing for enhanced EMI protection. Its low power consumption (<1.0 W) makes it an energy-efficient choice for data centers and enterprise networks.

Suitable for

• Gigabit Ethernet (1000BASE-SX) connections in LANs and data centers
• Fiber Channel applications at 1.0625 or 2.125 Gbps
• Interconnecting switches, routers, and servers over multimode fiber
• Upgrading or expanding existing SFP-based network infrastructure

Key specifications

• Form Factor: SFP (Small Form-Factor Pluggable)
• Data Rate: 1.25 Gbps
• Wavelength: 850 nm
• Max Distance: 550 m (over OM2 MMF)
• Fiber Type: Multimode (MMF)
• Connector: LC Duplex
• DDM/DOM: Yes
• Operating Temperature: 0°C to 70°C
• Power Consumption: <1.0 W
• Compliance: IEEE 802.3z, SFP MSA

Recommendations

For optimal performance, pair this SFP module with OM2 or OM3 multimode fiber patch cables. Ensure your network equipment supports SFP MSA-compliant modules. This transceiver is a direct replacement for Finisar FCLF-8520-3 and is backed by BlueOptics' quality guarantee.
