BlueOptics Fortinet FN-CABLE-QSFP28-2 Compatible BlueLAN SC282801L2M30 QSFP28 Direct Attach Cable, 100GBASE-CR4, 30AWG, 2 Meter

The BlueOptics Fortinet FN-CABLE-QSFP28-2 Compatible BlueLAN SC282801L2M30 is a high-performance QSFP28 Direct Attach Cable (DAC) designed for 100 Gigabit Ethernet connectivity. This passive copper cable delivers reliable, low-latency interconnects for data centers and enterprise networks, ensuring seamless integration with Fortinet equipment.

Advantages

This DAC cable offers a cost-effective and energy-efficient solution for short-range 100G connections. With its passive design, it consumes minimal power while providing full 100 Gbps throughput. The 30 AWG construction ensures flexibility and easy cable management, while the 2-meter length is ideal for rack-to-rack or top-of-rack switching.

Suitable for

• Data center interconnects
• High-performance computing (HPC) clusters
• Enterprise network aggregation
• Fortinet switch and router uplinks

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Form Factor: QSFP28
• Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-CR4
• Cable Length: 2 meters
• Wire Gauge: 30 AWG
• Cable Material: Twinax Copper
• Connector Type: QSFP28 to QSFP28
• Transceiver Type: Passive Copper Cable
• Compatibility: Fortinet FN-CABLE-QSFP28-2 Compatible
• Hot-Swappable: Yes
• Power Consumption: Low
• Impedance: 100 Ohm
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Certifications: RoHS, CE, FCC

Recommendations

For optimal performance, pair this cable with compatible QSFP28 ports on Fortinet switches or other 100GBASE-CR4 compliant equipment. Ensure proper cable routing to maintain signal integrity.
