BlueOptics BO05A15680D SFP Transceiver, LC-Duplex, 100BASE-ZX, Singlemode Fiber, 1550nm, 80km, DDM, 0°C/+70°C, Compatible with Huawei 02317345

The BlueOptics BO05A15680D SFP transceiver is a high-performance, cost-effective solution designed for 100BASE-ZX Ethernet applications over singlemode fiber. It is fully compatible with Huawei 02317345 equipment, ensuring seamless integration and reliable operation. This hot-pluggable module supports digital diagnostic monitoring (DDM) for real-time performance tracking.

Advantages

This transceiver offers extended reach up to 80 km, making it ideal for long-distance network links. It operates at a wavelength of 1550 nm and supports full-duplex communication. The MSA-compliant design ensures interoperability with a wide range of networking devices.

Suitable for

• Enterprise and service provider networks requiring long-haul 100 Mbps connections
• Metropolitan area networks (MANs) and wide area networks (WANs)
• Upgrading or expanding existing fiber optic infrastructure

Key specifications

• Form Factor: SFP
• Data Rate: 100 Mbps
• Ethernet Standard: 100BASE-ZX
• Wavelength: 1550 nm
• Max Transmission Distance: 80 km
• Fiber Type: Singlemode (SMF)
• Connector Type: LC-Duplex
• DDM/DOM Support: Yes
• Operating Temperature: 0°C to +70°C
• Hot-Pluggable: Yes
• MSA Compliant: Yes
• Optical Source: DFB Laser
• Power Supply Voltage: 3.3 V
• Duplex Mode: Full-Duplex

Recommendations

For optimal performance, use with singlemode fiber patch cables (OS2) and ensure proper cleaning of LC connectors. This transceiver is a direct replacement for Huawei 02317345 and is backed by BlueOptics quality and reliability.
