BLUELAN Compatible Cisco QSFP-100G-CU50CM Direct Attach Cable, 100GBASE-CR4, Infiniband EDR, 30AWG, 0.5m

The BLUELAN QSFP-100G-CU50CM-BL is a high-performance direct attach copper (DAC) cable designed for 100 Gigabit Ethernet and InfiniBand EDR applications. This passive cable provides a cost-effective, low-power solution for short-range interconnects within data centers and high-performance computing environments.

Advantages

This DAC cable offers reliable connectivity with minimal latency and power consumption. Its passive design ensures zero power draw, making it an energy-efficient choice for dense deployments. The 30 AWG construction provides flexibility for easy cable management in tight spaces.

Suitable for

• Data center top-of-rack to server connections
• High-performance computing clusters
• Network storage systems
• InfiniBand EDR fabrics

Key specifications

• Cable Type: Direct Attach Copper (DAC) Passive
• Connector Type: QSFP28 to QSFP28
• Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-CR4
• InfiniBand Standard: EDR
• Cable Length: 0.5 meters (50 cm)
• Wire Gauge: 30 AWG
• Compatibility: Cisco QSFP28 100G ports and MSA compliant devices
• Jacket Material: PVC
• Operating Temperature: 0°C to 70°C
• Compliance: RoHS, CE, FCC, MSA Compliant

Recommendations

For optimal performance, ensure your switch or NIC supports QSFP28 100G ports. This cable is ideal for short-distance links up to 0.5 meters. For longer distances, consider active optical cables or fiber transceivers.
