BlueLAN Compatible Amphenol NDAAFF-0006 QSFP28 Direct Attach Copper Cable, 100GBASE-CR4, InfiniBand EDR, 30AWG, 2 Meter (NDAAFF-0006-BL)

The BlueLAN NDAAFF-0006-BL is a high-performance, passive Direct Attach Copper (DAC) cable designed for 100 Gigabit Ethernet and InfiniBand EDR applications. This cable is fully compatible with Amphenol NDAAFF-0006 and provides a cost-effective, low-power solution for short-range interconnects in data centers, HPC, and enterprise networks.

Advantages

This DAC cable offers reliable 100 Gbps connectivity with minimal power consumption (<0.5W) and low latency. Its passive design ensures plug-and-play operation without the need for external power. The 30 AWG construction provides flexibility for easy cable management, while the PVC jacket ensures durability and compliance with RoHS, CE, and FCC standards.

Suitable for

• Data center top-of-rack to server/storage connections
• High-performance computing (HPC) clusters
• Enterprise networking and cloud infrastructure
• InfiniBand EDR (Enhanced Data Rate) networks

Key specifications

• Product Type: Direct Attach Copper (DAC) Cable
• Connector Type: QSFP28 to QSFP28
• Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-CR4
• InfiniBand Standard: EDR
• Cable Length: 2 Meter
• Wire Gauge: 30 AWG
• Cable Material: Copper
• Transceiver Type: Passive
• Impedance: 100 Ohm
• Jacket Material: PVC
• Operating Temperature: 0°C to 70°C
• Hot-Swappable: Yes
• Certifications: RoHS, CE, FCC Compliant

Recommendations

For optimal performance, ensure your network equipment supports QSFP28 ports and 100GBASE-CR4 or InfiniBand EDR standards. This cable is ideal for short-reach interconnects up to 2 meters.
