BCS ULTRA BCS-U-FA 5MP Outdoor Bullet IP Camera with PoE, 2.8mm Lens, 30m IR, IP67

Monitoring outdoor areas at night or in harsh weather often means compromising on image clarity or dealing with complicated power setups. The BCS ULTRA BCS-U-FA solves this by combining a 5-megapixel sensor, built-in IR illumination up to 30 metres, and Power over Ethernet (PoE) support in a rugged IP67-rated metal housing. One network cable delivers both data and power, simplifying installation while ensuring crisp, detailed footage around the clock.

Who is it for

This camera is built for small business owners, facility managers, and homeowners who need dependable outdoor surveillance without the hassle of separate power lines. Whether you are securing a parking lot, warehouse entrance, or residential perimeter, the BCS-U-FA offers professional-grade monitoring in a compact bullet form factor.

Main features

• 5MP progressive scan CMOS sensor delivers sharp 2592 x 1944 resolution for identifying faces and licence plates.
• Fixed 2.8mm lens with a wide 100° horizontal field of view covers broad areas with a single camera.
• Smart IR night vision reaches up to 30 metres, automatically switching to black-and-white in low light.
• H.265+ compression reduces bandwidth and storage needs by up to 70% compared to H.264, without sacrificing quality.
• Built-in microphone captures ambient audio, adding another layer of situational awareness.
• IP67 weatherproof metal housing withstands rain, dust, and temperatures from -30°C to +60°C.
• PoE (802.3af) support means a single Ethernet cable handles power and data, cutting installation time and cost.
• MicroSD card slot supports up to 256GB for local recording, with no mandatory cloud subscription.

Specifications

• Image sensor: 1/2.7" 5MP progressive scan CMOS
• Max resolution: 2592 x 1944 @ 20fps
• Lens: 2.8mm fixed, horizontal FoV approx. 100°
• IR range: up to 30m, ICR cut filter for true day/night
• Video compression: H.265+, H.265, H.264+, H.264
• Audio: built-in microphone
• Network: 1x RJ45 10/100Mbps Ethernet
• Power: DC 12V or PoE (802.3af)
• Local storage: MicroSD up to 256GB
• Ingress protection: IP67
• WDR: Digital WDR
• Smart features: motion detection, privacy masking, ROI
• Operating temperature: -30°C to +60°C
• Housing: metal

Tips

For the best night vision, mount the camera at a height of 3–4 metres and angle it slightly downward to avoid IR reflection from walls or eaves. If you use a PoE switch, ensure it supports 802.3af to power the camera without an extra adapter. Format the MicroSD card in the camera before first use to prevent recording errors.
