BCS BCS-EA45VSR8L6 5MP HD Analog Bullet Camera with Motorized Varifocal Lens, 80m Smart IR, 120dB True WDR, IP67

High-definition analog surveillance reaches new clarity with the BCS-EA45VSR8L6, a 5-megapixel bullet camera engineered for demanding outdoor security. Its 1/2.7" CMOS sensor delivers 2592x1944 resolution, capturing fine details like faces and license plates even at distance. The motorized 2.7-13.5mm varifocal lens offers remote zoom and focus adjustment, eliminating manual tweaking after installation. With 120dB True WDR, the camera balances extreme lighting contrasts, ensuring clear images in scenes with both bright sunlight and deep shadows. Smart IR illumination reaches up to 80 meters in total darkness, while the IP67-rated metal housing withstands rain, dust, and temperatures from -30°C to 60°C. Four-in-one video output (HDCVI/AHD/TVI/CVBS) ensures compatibility with most existing DVRs, making it a versatile upgrade for any analog system.

Advantages

The BCS-EA45VSR8L6 excels in challenging environments where detail and reliability are paramount. Its motorized varifocal lens allows precise remote adjustment, saving time on ladders and lifts. True WDR handles high-contrast scenes without blown highlights or lost shadows, while 2D/3D noise reduction keeps footage clean in low light. The robust metal body and IP67 rating guarantee long-term operation outdoors, and the 80m Smart IR range covers large perimeters effectively. Multi-format output future-proofs your investment, working seamlessly with HDCVI, AHD, TVI, or CVBS recorders.

Suitable for

• Perimeter surveillance of warehouses, parking lots, and industrial sites
• Entrances and building facades requiring long-range night vision
• Retrofit projects upgrading existing analog CCTV systems to 5MP
• Areas with challenging lighting, such as loading docks or gatehouses
• Outdoor locations exposed to harsh weather conditions

Key specifications

• Sensor: 1/2.7" CMOS, 5 Megapixel (2592x1944)
• Lens: Motorized varifocal 2.7-13.5mm, horizontal angle 102°-29°
• Video output: 4-in-1 (HDCVI / AHD / TVI / CVBS)
• IR illumination: Smart IR up to 80m, minimum illumination 0.005 lux (color)
• WDR: 120dB True WDR, BLC/HLC, AGC, 2D/3D DNR
• Housing: Metal, IP67 weatherproof, operating temperature -30°C to +60°C
• Power: DC12V, max consumption 8.2W (IR on)

Recommendations

Pair this camera with a 5MP-capable HDCVI DVR to fully utilize its resolution. For optimal night vision, mount at a height of 3-5 meters and avoid pointing directly at reflective surfaces. Use the motorized zoom to set the field of view remotely before finalizing installation, and ensure the power supply can deliver at least 1A at 12V DC.
