BCS B-SP16G-2SFP-M Industrial Unmanaged 16-Port Gigabit PoE+ Switch with 2 SFP Slots, 240W PoE Budget, DIN-Rail Mount

On a factory floor, where cables run alongside heavy machinery and temperatures fluctuate, the BCS B-SP16G-2SFP-M industrial switch proves its worth. It feeds power to security cameras and wireless access points while moving data at gigabit speed, all without a single fan. This plug-and-play unmanaged switch is built to survive harsh conditions, so your network stays up even when the environment tries to bring it down.

Key specifications

• 16 x 10/100/1000Base-T Gigabit Ethernet RJ45 ports
• 2 x 1000Base-X SFP slots for fiber uplinks or network rings
• PoE+ on all 16 ports (IEEE 802.3af/at), total budget 240W
• Switching capacity: 36 Gbps
• Packet forwarding rate: 26.78 Mpps
• MAC address table: 8K entries
• Jumbo frame support: 9KB
• Wide operating temperature: -40°C to 75°C
• IP40 rated metal housing, DIN-rail or wall mount
• Redundant DC terminal block (48-57V) with 6kV surge/ESD protection

Why choose it

Reliability is the watchword. The switch delivers power to all 16 ports simultaneously, enough for power-hungry PTZ cameras or outdoor radios. The redundant power input keeps the network alive if one feed fails, while the fanless design ensures silent, maintenance-free operation in dusty enclosures. With a 240W PoE budget, you can run high-power devices without extra wiring.

Ideal use cases

• IP surveillance in industrial plants, parking garages, and remote sites
• Wireless access points and mesh nodes in outdoor networks
• Automation and control systems in manufacturing and processing
• Building management and smart infrastructure projects

Good to know

As an unmanaged switch, it requires no configuration – just connect power and Ethernet cables. The IP40 metal housing protects against dust and minor impacts, while the -40°C to 75°C operating range covers most extreme climates. Whether you need copper to the edge or fiber uplinks, this switch handles it all in one rugged package.
