Backplate Alphacool 10269 Acrylic Aluminium Chrome Copper Nylon Black 155.5x235.9x34mm

The Alphacool 10269 backplate is part of Alphacool's Core series accessories for custom GPU water cooling. Made from acrylic, aluminium and chrome-finished copper with nylon details, this backplate covers the rear of a compatible GPU water block and contributes to a uniform visual appearance while supporting heat dissipation and protecting the PCB. Its dimensions are 155.5 x 235.9 x 34 mm and the product is finished in black and chrome to match modern builds.

Advantages

The design uses a full-coverage aluminium backplate combined with a precision-machined copper base and acrylic elements, delivering a uniform look and reliable mechanical protection for the GPU water cooler. A chrome finish on copper parts improves surface durability and produces a smooth, radiant appearance. High-quality brass connectors and nylon-covered terminals enhance connection reliability and safety. The component layout and waterflow geometry were revised and tested to ensure compatibility and effective integration with Alphacool Core-series GPU water blocks.

Suitable for

• Custom GPU water-cooling builds using Alphacool Core-series GPU water blocks
• PC builds that require a full-coverage rear backplate for protection and aesthetics
• Systems where black and chrome finishes are desired to match other cooling components

Key specifications

• Dimensions: 155.5 x 235.9 x 34 mm
• Materials: Acrylic, Aluminium, Chrome (on copper), Copper, Nylon
• Color: Black, Chrome
• Fitting / connector size reference in the series: 1/4"
• Pressure reference from series testing: 0.8 bar

How to use

Remove any original GPU shroud/backplate according to the GPU manufacturer's instructions. Align the Alphacool 10269 backplate with the corresponding Alphacool Core-series GPU water block and the GPU PCB mounting points. Secure the backplate using the supplied screws or mounting hardware, ensuring even torque on all fasteners. Connect the water cooling loop using the recommended 1/4" fittings and verify that all brass connectors and nylon-covered terminals are properly seated. After installation, perform a leak test and then power the system to confirm correct operation.

Recommendations

Install the backplate only with compatible Alphacool Core-series GPU water blocks and follow Alphacool's installation instructions. Perform a leak test before full operation and use appropriate thermal interface materials where required by the GPU water block manufacturer.
