ASUS 90DD0302-M29000 240mm All-in-One Liquid CPU Cooler with Addressable RGB and PWM Fans

High-performance processors push out immense heat that can quickly throttle system speed and reduce frame rates. The ASUS 90DD0302-M29000 is a 240mm all-in-one liquid cooler built to tame that heat effectively, ensuring your CPU runs consistently at peak performance. Whether you are a gamer, creator, or PC builder, this cooler delivers the thermal headroom needed for demanding workloads and overclocking.

Who is it for

This cooler is ideal for enthusiasts building high-end PCs with Intel or AMD platforms. It suits users who want the quiet efficiency of liquid cooling combined with eye-catching Addressable RGB lighting. Gamers chasing higher boost clocks, content creators rendering 4K videos, and professionals relying on CPU-heavy applications will all benefit from the steady, low temperatures this unit provides.

Main features

• 240mm aluminum radiator that facilitates rapid heat exchange and low-noise operation.
• Two 120mm ROG-designed ARGB fans with PWM control from 800 to 2500 RPM, providing high airflow (up to 80.8 CFM) and static pressure (up to 5.0 mmH2O) while keeping noise to a maximum of 37.6 dB(A).
• Copper cold plate efficiently absorbs heat from the CPU, transferring it to the liquid loop with minimal thermal resistance.
• Addressable RGB lighting on the pump and fans, fully compatible with ASUS Aura Sync for custom lighting effects and synchronization across components.
• Wide socket compatibility: supports Intel LGA 1700, 1200, 115x, 2011, 2066 and AMD AM5, AM4, TR4 (with included mounting bracket).
• Integrated pump with an 800-2800 RPM motor ensures reliable coolant circulation, and the 380mm sleeve tube offers flexible installation in most mid-tower cases.
• Backed by a 6-year warranty, reflecting the cooler’s build quality and long-term durability.

Specifications

• Cooler Type: Liquid CPU Cooler (AIO)
• Radiator Size: 240mm
• Radiator Material: Aluminum
• Fan Size: 2 x 120mm
• Fan Speed: 800 - 2500 RPM (±10%)
• Max Fan Airflow: 80.8 CFM
• Max Fan Static Pressure: 5.0 mmH2O
• Fan Noise Level: 37.6 dB(A) (Max)
• Pump Speed: 800 - 2800 RPM (±10%)
• Cold Plate Material: Copper
• Tube Length: 380 mm
• RGB Lighting: Addressable RGB (Aura Sync compatible)
• Intel Socket Support: LGA 1700, 1200, 115x, 2011, 2066
• AMD Socket Support: AM5, AM4, TR4 (with bracket)
• Fan Power Connector: 4-pin PWM
• Pump Power Connector: 3-pin
• Warranty: 6 Years

Tips

Before mounting, confirm that your case has an available 240mm radiator mounting position (top or front) with proper clearance. When installing the pump, ensure even pressure on the CPU IHS and coat the base with the included thermal compound. For optimal airflow, align the radiator fans to exhaust out of the case. Always follow the manufacturer's instructions and check that the mounting brackets match your socket.
