Akyga Ultimate AK-U4-500 500W ATX Power Supply

The Akyga Ultimate AK-U4-500 is a reliable 500W ATX power supply designed for desktop computers. With Active PFC and over 70% efficiency, it delivers stable power while meeting essential safety standards. Ideal for office PCs, home systems, and entry-level gaming builds.

Advantages

Active PFC ensures efficient power usage and reduced harmonics. The 120mm fan provides quiet cooling. Multiple protection features (OVP, OCP, OPP, OTP, SCP, UVP) safeguard your components. CE and RoHS certified for quality and environmental compliance.

Suitable for

• Office and home desktop computers
• Entry-level gaming PCs
• Systems requiring up to 500W power

Key specifications

• Total Power Output: 500 W
• Form Factor: ATX
• Efficiency: >70%
• PFC Type: Active PFC
• Fan Diameter: 120 mm
• Modularity: Non-modular
• ATX 20+4 Pin Connector: 1
• CPU 4+4 Pin (EPS) Connector: 1
• PCI-E 6+2 Pin Connector: 1
• SATA Power Connectors: 3
• Molex (4-pin peripheral) Connectors: 2
• Floppy Power Connectors: 1
• Input Voltage: 230 V
• Input Frequency: 50 Hz
• Protection Features: OVP, OCP, OPP, OTP, SCP, UVP
• MTBF: 100,000 hours
• Certifications: CE, RoHS
• Max. Load on +12V Rail: 30 A (360 W)
• Max. Load on +5V Rail: 15 A
• Max. Load on +3.3V Rail: 15 A

Recommendations

Ensure your case supports ATX power supply form factor. For optimal performance, use with a surge protector. This unit is non-modular; plan cable management accordingly.
