AHD HD-CVI HD-TVI Camera APTI-H51V2-36 2MP Full HD 1080p Bullet Security Camera with 3.6mm Lens, 20m IR Night Vision, IP66 Weatherproof, Metal Housing, DC 12V

Capture crisp 1080p Full HD video day and night with the APTI-H51V2-36, a versatile bullet camera supporting AHD, HD-CVI, HD-TVI, and CVBS signals. Its 1/2.7" CMOS sensor and 3.6mm fixed lens deliver a 90° horizontal field of view, while 18 SMD IR LEDs provide up to 20 meters of night vision in total darkness. Built with an IP66-rated aluminum alloy housing, this camera withstands harsh weather, making it ideal for outdoor surveillance.

Overview

The APTI-H51V2-36 is a high-definition analog HD camera designed for flexible integration with existing DVR systems. It automatically switches between HD-TVI, AHD, HD-CVI, and CVBS video output modes, ensuring compatibility with a wide range of recorders. The camera's OSD menu, accessible via UTC control, allows fine-tuning of image settings such as white balance, exposure, and digital noise reduction directly from the DVR.

What stands out

• 2MP Full HD 1080p resolution for sharp, detailed footage.
• Quad-mode video output: HD-TVI, AHD, HD-CVI, CVBS.
• Powerful IR night vision up to 20 meters with 18 SMD LEDs.
• IP66 weatherproof metal housing for outdoor durability.
• Digital Wide Dynamic Range (DWDR) and 2DNR for challenging lighting.
• UTC control for remote OSD configuration.

Technical details

• Sensor: 1/2.7" CMOS
• Lens: 3.6mm fixed, horizontal angle approx. 90°
• Minimum illumination: 0.01 Lux (F1.2, AGC ON), 0 Lux with IR
• IR range: up to 20m, 18x SMD IR LEDs
• Video output: HD-TVI, AHD, HD-CVI, CVBS (switchable)
• Power: DC 12V, max 3W consumption
• Housing: aluminum alloy, IP66 rated
• Mounting: wall/ceiling bullet
• Features: DWDR, 2DNR, BLC, AGC, auto/manual white balance

Our verdict

Combining multi-format compatibility, robust weatherproofing, and clear night vision, the APTI-H51V2-36 is a reliable choice for both residential and commercial surveillance. Its metal construction and advanced image processing ensure consistent performance in varied environments.
