Aerocool VX PLUS 650 power supply unit 650 W 20+4 pin ATX ATX Black

The Aerocool VX PLUS 650 is a 650W power supply unit designed for entry-level PC builds. It provides 650 watts of total power, a 20+4 pin ATX motherboard connector, active cooling with a 120 mm fan, and comes in a black finish. The unit supports AC input at 230V and 47–63 Hz and includes SATA and PCI Express power cables for typical desktop configurations.

Advantages

The VX PLUS 650 offers an attractive price-to-performance ratio for budget-conscious builders and features an improved top cover design that enhances the appearance of a gaming setup. An upgraded transformer balances the 12V, 5V and 3.3V rails for more stable voltage regulation under load, and the optimized 12 cm fan with smart speed control reduces noise at low to moderate loads.

Suitable for

• Entry-level gaming PCs
• Office and home desktop computers
• Budget system builds requiring up to 650W
• Systems using SATA and single PCIe-powered graphics cards

Key specifications

• Total power: 650 W
• Motherboard connector: 20+4 pin ATX
• Fan diameter: 120 mm (active cooling)
• AC input: 230 V, 47–63 Hz
• Cable types/lengths: SATA (150 mm, 300 mm), PCI Express (400 mm)
• Colour: Black

How to use

Install the Aerocool VX PLUS 650 into a compatible PC case following standard ATX PSU mounting procedures, connect the 20+4 pin ATX connector to the motherboard, and attach SATA and PCIe cables to drives and components as required. Ensure the mains supply matches the specified AC input and secure all cable connections before powering on the system.

Recommendations

Place the PSU in a case location with adequate airflow, keep intake vents free of dust, and ensure the ambient temperature remains near 25℃ for optimal fan behaviour. For systems with high-power graphics cards, verify total system load stays within the 650W rating.
