XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W

XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
XPG PYLON 750W Power Supply, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 120 W
R1,381
XPG PYLON offers more than just a Bronze-certified Power Supply. Highly efficient DC-to-DC converters and continuous power in 4 different wattage options are making it an ideal PSU pick for all usages.DC-to-DC Circuit in BRONZE GradeXPG PYLON complies with Intel ATX Power Supply Design Guide‘s sleep... Read More
Stock Out Of Stock Code 126149 Brand ADATA Model 75261508 Warranty 2 Years

Shipping & Returns

XPG PYLON offers more than just a Bronze-certified Power Supply. Highly efficient DC-to-DC converters and continuous power in 4 different wattage options are making it an ideal PSU pick for all usages.

DC-to-DC Circuit in BRONZE Grade

XPG PYLON complies with Intel ATX Power Supply Design Guide‘s sleep mode function, featuring DC-to-DC 100% +12V Full Power in all PYLON series, ensuring that power delivery remains consistent, power-efficient, and capable of supporting mid to high-end graphic cards and CPUs.

80 Plus Bronze Certification

XPG PYLON is a 80 Plus Bronze certified power supply unit that guarantees energy efficiency at 20%, 50% and 100% of rated loads. XPG PYLON also complies with ErP 2014 Lot 3 Regulation, and it is designed for steady 24/7 Continuous Power system operation.

Cybenetics ETA and LAMBDA Certified

XPG PYLON SERIES is certified by Cybenetics for its efficiency and noise level, scoring at the top of its category in both ETA and LAMBDA standards.

120mm Fluid Dynamic Bearing (FDB) Fan

The fan control of the built-in 120mm Fluid Dynamic Bearing (FDB) Fan starts at around 700 rpm (25°C ambient) and maintains its low fan speed until around 70% power load.
The operating environment is kept quiet and efficient, and prolongs its life expectancy.

Main Japanese Capacitor at 105°C

High quality 105°C Main Japanese Capacity in XPG PYLON Bronze Series ensures great durability and offer highest stability and reliability.

8 Industrial-Level Protections

XPG PYLON is designed for both efficiency and safety, and backed up by a 3-Year warranty. Fundamental protections such as OPP, UVP, OVP, SCP, OTP and OCP are all included, as well as NLO and SIP which are found in mid to high-end PSU, offering one of the highest standards of stability and security in this category.

XPG PYLON 750W Power Supply. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Silver. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: AC

Key Highlights
  • DC to DC Converters
  • 80PLUS BRONZE Certified
  • Continuous Power for 24/7 system operation
  • 120mm FDB Silent-Performance Fan
  • High Current +12V rail system compatibility
  • Main Japanese Capacitor
  • Multiple PCI-E 2.0 6+2 Pin Connectors
  • Industrial-Level Protection OVP, OPP, SCP, OCP, UVP, OTP, NLO, SIP
  • Complies with ErP 2014 Lot 3
  • RoHS Compliance
  • 750 W 100 - 240 V 50/60 Hz
  • Motherboard power connector: 24-pin ATX
  • PC ATX 80 PLUS Silver
  • Active 12 cm 0 - 2000 RPM
  • Black
Specifications
80 PLUS certification
80 PLUS Silver
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
ATX Power connector (24-pin)
Yes
ATX version
2.4
Bearing technology
FDB
Cables included
AC
Cabling type
Non-Modular
Certification
CE / CB(62368+60950) / FCC(IC) / EAC / CCC / TUV / cTUVus / TUV-S / RCM / NOM / BSMI / KC
Combined power (+12V)
750 W
Combined power (+3.3V)
120 W
Combined power (+5V)
120 W
Combined power (+5Vsb)
12.5 W
Combined power (-12V)
3.6 W
Compliance certificates
RoHS
Cooling type
Active
Depth
150 mm
EPS power connector (4+4 pin)
Yes
Fan diameter
12 cm
Fan speed
0 - 2000 RPM
Harmonized System (HS) code
84733020
Height
86 mm
Input current
10 - 5 A
Max output current (+12V)
62.5 A
Max output current (+3.3V)
20 A
Max output current (+5V)
20 A
Max output current (+5Vsb)
2.5 A
Max output current (-12V)
0.3 A
Mean time between failures (MTBF)
100000 h
Motherboard power connector
24-pin ATX
Number of fans
1 fan(s)
Number of SATA power connectors
8
On/off switch
Yes
Package weight
2.63 kg
PCI Express power connectors (6+2 pin)
4
Peripheral (Molex) power connectors (4-pin)
3
Power factor
0.99
Power Factor Correction (PFC) type
Active
Power protection features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power supply unit (PSU) form factor
ATX
Product colour
Black
Purpose
PC
Sustainability certificates
ErP
Sustainability compliance
Yes
Total power
750 W
Weight
2.12 kg
Width
140 mm

Manual

Open Manual

Leaflet

Open Leaflet
