ABUS SECURITY-CENTER AU1320 Standalone Access Control Controller with Wiegand Interface

The ABUS AU1320 stands out as a compact standalone access control controller that brings professional-grade door management to small installations without the complexity of a networked system. While many controllers demand a permanent PC connection, this unit operates independently, storing up to 1000 users and 2000 events locally, making it ideal for offices, shops, or residential buildings where simplicity and reliability are paramount.

Highlights

• Standalone operation with no PC required for daily use
• Supports up to 1000 users and 2000 event records
• Wiegand 26-bit and 34-bit reader interface for compatibility with ABUS readers AU1310, AU1311, AU1312
• One door control with relay output for door opener (NO/NC) and separate alarm relay
• Inputs for door contact and exit button
• Master card and programming card for easy configuration
• Adjustable door opening time from 1 to 99 seconds
• Simple anti-passback function for one door
• Five time zones for flexible access scheduling
• 12 V DC power supply, low current consumption (max. 100 mA without reader)

In daily use

Installation is straightforward: connect the controller to a Wiegand reader, a door lock, and a 12 V DC power supply. Programming can be done via master card, programming card, or the optional AU1100 PC software. The controller logs every access attempt, and the built-in buzzer provides audible feedback. The plastic housing is rated IP20 for indoor use, and the operating temperature range of -20°C to +60°C ensures reliable performance in most environments. With its compact dimensions and DIN-rail mountable design (mounting bracket included), the AU1320 fits neatly into electrical cabinets.

Full specifications

• Product type: Access control controller
• System type: Standalone
• Max. users: 1000
• Max. event memory: 2000 events
• Controlled doors: 1
• Reader interface: Wiegand (26-bit, 34-bit)
• Power supply: 12 V DC
• Current consumption: max. 100 mA (without reader)
• Relay outputs: 1x door opener (NO/NC), 1x alarm
• Inputs: 1x door contact, 1x exit button
• Programming: Master card, programming card, PC software (AU1100)
• Time zones: 5
• Anti-passback: Yes (simple, for one door)
• Door opening time: adjustable 1-99 seconds
• Operating temperature: -20°C to +60°C
• Protection class: IP20
• Housing material: Plastic
• Compatibility: ABUS Wiegand readers (e.g., AU1310, AU1311, AU1312)
• Mounting: DIN rail (bracket included)

Final note

The ABUS AU1320 is a reliable, no-nonsense access control solution for single-door applications, offering robust standalone functionality and easy integration with ABUS readers. Its low power draw and wide temperature tolerance make it a durable choice for long-term use.
