ABUS 74/40HB38 Rouge Insulated Lockout Tagout Padlock Red with 1 Key, 6.5mm Shackle

Insulated lockout tagout padlock engineered for industrial safety, featuring a fully non-conductive plastic body and plastic-coated hardened steel shackle to prevent electrical conductivity during lockout procedures. The red body provides high visibility, while the key-retaining function ensures the key cannot be removed unless the padlock is locked, preventing accidental key loss.

Advantages

Lightweight, robust plastic body with hardened steel shackle coated in non-conductive plastic. Fully insulated design protects against electrical hazards. Corrosion-resistant and suitable for temperatures from -20°C to +80°C. OSHA compliant for lockout/tagout applications. Key-retaining function: key can only be removed when padlock is locked, enhancing safety and key management.

Suitable for

• Industrial lockout/tagout (LOTO) procedures
• Electrical isolation and energy control
• Safety lockout stations and group lockout boxes
• Maintenance, repair, and operations in manufacturing, chemical, and utility sectors

Key specifications

• Body width: 40 mm
• Shackle diameter: 6.5 mm
• Vertical shackle clearance: 25 mm
• Horizontal shackle clearance: 20 mm
• Body material: Lightweight, robust plastic
• Shackle material: Hardened steel with non-conductive plastic coating
• Keying: Keyed Different (KD), 1 key supplied
• Key-retaining function: Yes
• Temperature resistance: -20°C to +80°C
• Compliance: OSHA compliant for LOTO

Recommendations

For maximum safety, pair with ABUS lockout hasps and tags. Store keys in a central lockout station to maintain control. Regularly inspect shackle coating for damage to ensure insulation integrity.
