Yealink W76P IP phone Grey 20 lines TFT

The Yealink W76P is a grey IP mobile phone system that pairs the W56H wireless handset with the W70B DECT base station to provide a scalable multi-handset solution for small and medium-sized businesses. The system supports up to 10 registered W56H handsets, 10 SIP accounts and up to 20 simultaneous calls. It includes a 2.4-inch TFT display handset, built‑in speakerphone, Bluetooth and a 1.9 GHz DECT connection, and supports Ethernet 10/100 Mbit/s with IEEE 802.1af power standards.

Advantages

The W76P delivers stable audio through support for Opus and multiple audio codecs and implements a Noise Reduction System for clearer conversations in noisy environments. It allows extended coverage with up to six optional repeaters and offers centralized provisioning and remote management via Yealink RPS and standard boot mechanisms. The system is compatible with the Yealink DECT ecosystem—handsets, conference phones and DD phones—enabling flexible deployment across different workspace layouts.

Suitable for

• Small and medium-sized business voice communications
• Multi-line mobile desk and on‑site staff use
• Environments requiring extended DECT coverage with repeaters
• Deployments needing centralized provisioning and remote maintenance

Key specifications

• Model: Yealink W76P (grey), MPN W76P, EAN 6938818308671
• Handset display: 2.4-inch TFT
• Lines: Up to 20 lines supported on the system
• SIP accounts: Up to 10
• Concurrent calls: Up to 20
• DECT frequency band: 1.9 GHz
• Maximum registered handsets: 10 W56H handsets
• Repeaters: Support for up to 6 optional repeaters
• Audio: Opus and multiple codecs; Noise Reduction System
• Connectivity: Ethernet 10/100 Mbit/s; IEEE 802.1af
• Features: Speakerphone, Bluetooth, wireless handset
• Power: AC adapter 100–240 V (device supports PoE per IEEE 802.1af)
• Colour: Grey

How to use

Install the W70B base station at a central location and power it via PoE or the AC adapter. Register up to 10 W56H handsets to the base station following the handset registration procedure. Configure SIP accounts and call routing through the web portal or your PBX. Add optional repeaters where needed to extend DECT coverage. For large deployments, use Yealink RPS and boot mechanism to provision devices remotely and perform bulk updates.

Recommendations

Place the W70B base station in an elevated, central position away from large metal objects for best DECT range; use optional repeaters to cover remote areas and enable Opus codec for improved audio quality in varying network conditions.
