Wireless router Cudy IR04_EU 300 Mbps, 2.4 GHz Wi‑Fi 4 (802.11n), 4x Fast Ethernet, 1x USB 2.0, LTE (4G) support

Cudy IR04_EU is a compact wireless router with built-in 4G support, delivering up to 300 Mbps on the 2.4 GHz band using Wi‑Fi 4 (802.11n). It is equipped with a 580 MHz single-core processor, 128 MB of internal memory and 16 MB of flash storage, two internal antennas in a 2x2 MIMO configuration, four Fast Ethernet LAN ports and one USB 2.0 port. The aluminium-alloy housing includes LED power indication and a reset button. The router accepts 100–240 V AC input and provides a 12 V DC output at 1 A, and operates in a wide temperature and humidity range.

Advantages

The router supports both LTE-TDD and LTE-FDD networks and is compatible with WCDMA 3G standards, enabling mobile broadband connectivity where wired internet is unavailable. Internal 2x2 MIMO antennas and Wi‑Fi 4 deliver stable wireless coverage on the 2.4 GHz band. Multiple wired interfaces, including four Fast Ethernet LAN ports and a USB 2.0 port, provide flexible connectivity options for home or small office setups. Compact aluminium-alloy construction and wide operating temperature and humidity tolerances make the device suitable for varied installation environments.

Suitable for

• Home internet access using ADSL/cable fallback to 4G mobile network
• Small office or remote site requiring mobile broadband backup
• Connecting wired devices via multiple Fast Ethernet LAN ports
• Basic file sharing or media access using the USB 2.0 port

Key specifications

• Wireless: 2.4 GHz band, Wi‑Fi 4 (802.11n), up to 300 Mbps
• Processor: 580 MHz single-core
• Memory: 128 MB RAM, 16 MB flash
• Antennas: 2 internal antennas, 2x2 MIMO
• LAN: 4 x Fast Ethernet (RJ-45)
• USB: 1 x USB 2.0
• Power: AC input 100–240 V, 50/60 Hz; DC output 12 V, 1 A
• Operating temperature: -40 to 75 °C
• Operating humidity: 5–95% (non-condensing)
• Dimensions (W×H×D): 129 × 50.6 × 114 mm
• Weight: 462 g
• Certifications: FCC

How to use

Connect the router to a power source using the provided DC input or appropriate adapter, then attach a LAN cable to one of the Fast Ethernet ports for wired devices or to a modem if required. Insert a compatible SIM card for 4G connectivity where applicable and follow the quick installation guide to complete initial configuration via the web interface. Configure wireless SSID and security settings for the 2.4 GHz network, enable mobile network preferences if using LTE backup, and connect client devices via Wi‑Fi or Ethernet as needed.

Recommendations

Place the router in a central, elevated location for best 2.4 GHz coverage; avoid strong electromagnetic interference and large metal objects. Regularly update firmware using the device web interface and use WPA2 security for the wireless network. For stable power delivery, use a compatible 12 V 1 A adapter and ensure adequate ventilation around the aluminium housing.
