Wired dynamic vocal microphone Sennheiser EW-D 835-S with UHF wireless system, cardioid, max SPL 154 dB, Bluetooth, XLR-3

Sennheiser EW-D 835-S is a wired dynamic vocal microphone paired with a stationary UHF wireless system. The microphone has a cardioid polar pattern, sensitivity of 2.1 mV/Pa and a maximum sound pressure level of 154 dB. The system operates in the 470.2–526 MHz RF range, the transmitter supports Bluetooth and can be powered by batteries or a rechargeable accumulator. The receiver includes a display, two external antenna connectors and is supplied with a mounting kit.

Advantages

The cardioid dynamic capsule provides focused pickup for vocals while reducing off-axis noise. Wide RF coverage in the 470.2–526 MHz band and low harmonic distortion ensure stable wireless transmission and clear audio. The transmitter’s Bluetooth support and battery/accumulator power options increase flexibility for different setups. The stationary receiver offers a clear display and dual external antenna connectors for improved reception.

Suitable for

• Live vocal performances
• Presentations and speeches
• Stage and rehearsal use

Key specifications

• Maximum temperature: 55 °C
• Minimum operating temperature: -10 °C
• Operating frequency type: UHF (470.2–526 MHz)
• Radio Frequency range: 470.2 - 526 MHz
• Harmonic distortion (THD): ≤ -60 dB at 1 kHz
• Non-operating relative humidity (non-condensing): 5 - 95%
• Headphone frequency response: 20 - 20000 Hz
• Transducer type: Dynamic
• Directional characteristics: Cardioid
• Sensitivity: 2.1 mV/Pa
• Maximum SPL: 154 dB
• Transmitter dimensions (H×W×D): 268 × 50 × 50 mm
• Transmitter weight: 304 g
• Receiver type: Stationary receiver
• Receiver dimensions (H×W×D): 44 × 189 × 212 mm
• Receiver weight: 1 kg
• External antenna connectors: 2
• Product colour: Black

How to use

Install the mounting kit as required for your setup, connect the receiver to your sound system via the XLR-3 output, and attach external antennas to the receiver connectors for best reception. Power the transmitter with batteries or a charged accumulator, switch on both transmitter and receiver, and tune the receiver to match the transmitter’s channel within the 470.2–526 MHz range. Position the microphone with its cardioid pickup facing the sound source to minimise off-axis noise. Use the receiver display to monitor signal and audio levels during operation.

Recommendations

Do not open the unit housing. For reliable wireless performance, place receiver antennas clear of large metal surfaces and maintain line of sight where possible. Replace or recharge batteries before long sessions and avoid operating the system outside the specified temperature and humidity ranges.
