Weidmüller Wire-End Ferrule, 6 mm², Blue, Insulated, 100 Pieces

The Weidmüller 1020280000 is a high-quality insulated wire-end ferrule designed for reliable electrical wiring termination. With a conductor cross-section of 6 mm² and a rated current of 41 A, it ensures secure and efficient connections in industrial and commercial applications. The blue insulation sleeve provides clear color coding for easy identification, while the tin-plated electrolytic copper contact material guarantees excellent conductivity and corrosion resistance.

Advantages

This ferrule offers precise crimping with a crimp length of 18 mm, ensuring a tight and durable connection. The polypropylene insulation withstands temperatures from -40 °C to +105 °C, making it suitable for demanding environments. Compliant with DIN 46228 Part 4 and RoHS, it meets stringent quality and environmental standards.

Suitable for

• Electrical wiring termination in control cabinets
• Industrial automation and machinery
• Power distribution systems
• Building and infrastructure installations

Key specifications

• Conductor cross-section: 6 mm²
• Rated current: 41 A
• Rated voltage: 300 V
• Color: Blue
• Insulation material: Polypropylene (PP)
• Contact material: Electrolytic copper, tin-plated
• Total length: 26 mm
• Crimp length: 18 mm
• Insulation sleeve length: 10 mm
• Outer diameter insulation: 6.5 mm
• Inner diameter metal sleeve: 3.5 mm
• Outer diameter metal sleeve: 3.8 mm
• Temperature range: -40 °C to +105 °C
• Packaging quantity: 100 pieces
• Standard: DIN 46228 Part 4
• RoHS compliant: Yes

Recommendations

For optimal performance, use with a compatible crimping tool designed for insulated ferrules. Ensure the conductor is stripped to the correct length before insertion.
