Weidmüller Feed-Through Terminal Block, PUSH IN, 10 mm², 57 A, 1000 V, Beige, 50 Pieces

The Weidmüller feed-through terminal block (model 1020300000) is a high-quality connection solution designed for reliable and efficient wiring in industrial applications. With PUSH IN connection technology, it enables fast, tool-free installation of solid and stranded conductors. Rated for 10 mm² cross-section, 57 A current, and 1000 V voltage, this terminal block is ideal for demanding electrical environments.

Advantages

PUSH IN technology reduces installation time and ensures secure connections. The compact design saves space on DIN rails, while the beige polyamide housing provides excellent insulation and durability. Rated for temperatures from -50 °C to 120 °C, it performs reliably in extreme conditions.

Suitable for

• Industrial control cabinets
• Building automation systems
• Power distribution panels
• Machine wiring

Key specifications

• Connection Technology: PUSH IN
• Nominal Cross-Section: 10 mm²
• Rated Current: 57 A
• Rated Voltage: 1000 V
• Color: Beige
• Number of Potentials: 1
• Number of Connections: 2
• Mounting Type: DIN Rail TS 35
• Insulating Material: PA (Polyamide)
• Flammability Rating: UL 94 V-0
• Operating Temperature: -50 °C to 120 °C
• Dimensions (L x W x H): 60 mm x 10 mm x 47 mm
• Quantity per Pack: 50 pieces

Recommendations

For optimal performance, use with compatible cross-connectors and end brackets. Ensure proper conductor stripping length as per manufacturer guidelines.
