VISION 50 m USB-C to HDMI Active Optical Cable - 4K@60Hz - Gold-Plated Connectors - DP 1.2 - HDMI 2.0 - CEC, EDID, HDR, HDCP 2.2 - USB-C 3.2 Male to HDMI Male - 4.5 mm Diameter - 18 Gbps - OM3 Fiber

The VISION TC50MUSBCHDMI+/BL is a high-performance 50-meter active optical cable designed to extend USB-C to HDMI signals with uncompromised 4K quality. Ideal for professional AV installations, digital signage, and conference rooms, this cable delivers reliable, long-distance transmission without signal degradation.

Advantages

Experience true 4K at 60 Hz over 50 meters using advanced active optical technology. The gold-plated connectors ensure corrosion-free, stable connections, while support for CEC, EDID, HDR, and HDCP 2.2 guarantees seamless integration with modern displays and sources. The slim 4.5 mm diameter allows easy routing in tight spaces.

Suitable for

• Extending USB-C laptop or tablet to HDMI projector or monitor in large rooms
• Digital signage and menu boards requiring long cable runs
• Professional AV setups in education, corporate, and hospitality environments

Key specifications

• Cable Length: 50 m
• Connector Type: USB-C Male to HDMI Male
• Max Resolution: 4K (3840x2160) @ 60 Hz
• HDMI Version: 2.0
• DisplayPort Alt Mode: DP 1.2
• Bandwidth: 18 Gbps
• Supported Features: CEC, EDID, HDR, HDCP 2.2
• Connector Plating: Gold
• Cable Outer Diameter: 4.5 mm
• Fiber Type: OM3 Multimode
• USB-C Standard: USB 3.2 (for DP Alt Mode)
• Directionality: Unidirectional (USB-C source to HDMI display)
• Power: Bus-powered from USB-C

Recommendations

For optimal performance, ensure your source device supports DisplayPort Alt Mode over USB-C. This cable is not reversible; connect the USB-C end to the source and HDMI end to the display. Compatible with Windows, macOS, and other operating systems with USB-C DP Alt Mode support.
