Video intercom DoorBird D2102V — IP65, IK08, IR LED, 10 m motion sensor, 15 V adapter (Black)

DoorBird D2102V is a black IP video intercom designed for building entrances and access control. The unit combines a 720p ultra-wide-angle camera with IR LED night illumination, a 10 m motion sensor, two-way audio and a wired network connection with PoE capability. Rated IP65 for water and dust protection and IK08 for impact resistance, the DoorBird D2102V is built for outdoor operation and comes with a 15 V AC adapter for installations without PoE.

Advantages

The DoorBird D2102V provides continuous video monitoring with night vision and an ultra-wide view, while the 4D motion sensor detects visitors up to 10 m away to trigger alerts or recordings. Two-way audio and a built-in speakerphone enable direct communication with callers. Robust mechanical and environmental protection (IP65, IK08) ensures reliable performance in exposed exterior locations, and PoE capability simplifies network power integration where available.

Suitable for

• Residential building entrances and apartment entry systems
• Small commercial properties requiring controlled access
• Outdoor gates and perimeter entry points with exposure to weather
• Installations that require night vision and motion-based detection

When it may not be suitable

This wired DoorBird intercom requires a network connection and either PoE or the supplied 15 V AC adapter; it is not suitable where only battery-operated or purely wireless solutions are acceptable. Environments that demand resolution above 720p or multi-camera integrated stations may require a different model.

Key specifications

• Camera: 720p ultra-wide-angle with 12 IR LEDs for night vision
• Motion detection: 4D motion sensor effective up to 10 m
• Audio: two-way audio with built-in speakerphone
• Protection class: IP65 (dust and water resistant), IK08 (impact resistant)
• Power: PoE capable or 15 V AC adapter (included where applicable)
• Installation: surface- or flush-mount options (housings sold separately)
• Connectors: wired LAN (PoE capable)
• Physical dimensions: Width 131 mm, Depth 48.8 mm, Height 313 mm
• Additional features: RFID reader, 2 configurable bistable relays

How to use

Mount the DoorBird D2102V in a weather-protected position using a compatible surface or flush housing. Connect the unit to the local network via Ethernet; if PoE is not available, connect the supplied 15 V AC adapter to power the device. Complete basic configuration through the DoorBird setup interface to enable video streaming, motion detection zones and two-way audio routing. Integrate the relays and the RFID reader into the existing access control system as required, and verify night-vision performance and motion-triggered notifications after installation.

What to consider before purchase

• Whether PoE is available or the 15 V AC adapter must be used
• Mounting method required (surface or flush housing and compatibility)
• Need for 720p resolution and single-camera capability versus higher-resolution systems
• Integration requirements with existing access control and RFID systems
• Environmental exposure to confirm IP65 and IK08 are sufficient

Recommendations

Position the unit to cover the main approach path for best motion detection up to 10 m, ensure the camera angle captures faces within the ultra-wide field, and configure motion sensitivity to reduce false alarms from traffic or vegetation. Test two-way audio levels and relay actions during commissioning to confirm reliable access control operation.
