VCX LC 43 Flush-Mounted RTV/SAT End Socket with 3 Outputs (TV, Radio, SAT) - White

With a wide frequency range spanning 5-2400 MHz and minimal insertion loss (as low as 1.5 dB), the VCX LC 43 ensures your TV, radio, and satellite signals arrive with exceptional clarity and strength. This flush-mounted end socket is engineered for modern multimedia installations, delivering three dedicated outputs (TV, Radio, SAT) from a single, elegant white wall plate.

Overview

The VCX LC 43 is a premium RTV/SAT end socket designed for residential and commercial coaxial distribution networks. It terminates the final connection point, providing separate outputs for terrestrial TV, FM/DAB radio, and satellite signals. The socket features an IEC male connector for TV, an IEC female for radio, and an F-type female for SAT, all with precise impedance matching for optimal signal transfer. Its Class A shielding and high isolation between outputs prevent interference, ensuring each signal remains clean and distinct.

What stands out

• Triple output design: simultaneous TV, radio, and satellite connections from one wall plate.
• Low insertion loss: only 1.5 dB for TV/Radio and 2.0 dB for SAT, preserving signal strength.
• Wide frequency coverage: 5-68 MHz and 120-862 MHz for TV, 87.5-108 MHz for radio, and 950-2400 MHz for SAT.
• DC pass-through for SAT: allows remote powering of LNB or multiswitches.
• Class A shielding and high isolation (>20 dB) between outputs to eliminate cross-interference.
• Flush-mounted design for a clean, professional finish in standard wall boxes.

Technical details

• Socket type: RTV/SAT end socket
• Number of outputs: 3 (TV, Radio, SAT)
• Mounting type: Flush-mounted
• Colour: White
• TV frequency range: 5-68 MHz, 120-862 MHz
• Radio frequency range: 87.5-108 MHz
• SAT frequency range: 950-2400 MHz
• TV attenuation (insertion loss): 1.5 dB
• Radio attenuation (insertion loss): 1.5 dB
• SAT attenuation (insertion loss): 2.0 dB
• TV connector type: IEC male (9.5 mm)
• Radio connector type: IEC female (9.5 mm)
• SAT connector type: F-type female
• DC pass for SAT: Yes (for LNB power)
• Shielding class: Class A
• Return loss: >10 dB
• Isolation (R-TV): >20 dB
• Isolation (R-SAT): >20 dB
• Isolation (TV-SAT): >20 dB

Our verdict

The VCX LC 43 is a top-tier choice for anyone needing a reliable triple-play wall socket. Its excellent signal integrity, robust shielding, and straightforward installation make it ideal for both new builds and retrofits. Whether you're setting up a home theatre or a multi-room distribution system, this socket delivers performance without compromise.
