VCX BLK 47 4-Pole Distribution Block 7 Holes 125A 690V Grey

The VCX BLK 47 is a high-quality distribution block designed for efficient power distribution in industrial and commercial electrical installations. With 4 poles and 7 terminals per pole (1 input, 6 outputs), it provides a total of 28 connection points, allowing for flexible and organized wiring. Rated at 125A and 690V AC, this block is suitable for demanding applications. The housing is made of durable polyamide (PA6) and the conductors are tinned copper/brass for excellent conductivity and corrosion resistance. It supports DIN rail (TH35) or screw mounting, making it versatile for various enclosures.

Advantages

High current rating of 125A ensures reliable power distribution. 7 terminals per pole (1 input, 6 outputs) offer ample branching options. Screw terminals provide secure and easy connections. Compact design saves space in control panels. Robust polyamide housing withstands harsh environments.

Suitable for

• Industrial control panels
• Power distribution systems
• Electrical cabinets and enclosures
• Commercial building installations

Key specifications

• Number of Poles: 4
• Terminals per Pole: 7 (1 Input, 6 Outputs)
• Total Terminals: 28
• Rated Current: 125 A
• Rated Voltage: 690 V AC
• Input Conductor Cross-section: 1 x 10-35 mm² (Flexible/Rigid)
• Output Conductor Cross-section: 6 x 1.5-10 mm² (Flexible/Rigid)
• Mounting Type: DIN Rail (TH35) / Screw Mount
• Housing Material: Polyamide (PA6)
• Conductor Material: Tinned Copper / Brass
• IP Rating: IP20
• Connection Type: Screw Terminal
• Operating Temperature: -25°C to +70°C
• Short-circuit Current (Icw): 20 kA
• Color: Grey

Recommendations

For optimal performance, ensure proper tightening torque as per manufacturer guidelines. Use appropriate cable lugs for larger cross-sections. This distribution block is ideal for organizing and distributing power in a safe and efficient manner.
