USB cable DELOCK 83629 — USB-C to Micro-USB B, USB 2.0, 7.5 m, Black

DELOCK 83629 is a 7.5 m USB data cable with a USB-C connector on one end and a Micro-USB B connector on the other, designed for data transfer and device charging where Micro-USB B devices must connect to USB-C hosts or adapters. The black jacket and extended length make it suitable for desktop setups, media equipment and situations that require a longer reach between host and device. The cable supports USB 2.0 signalling and is downwards compatible with USB 2.0 devices.

Advantages

The cable features a Micro-USB B connector with screws to secure the connection and reduce the risk of accidental unplugging. Its construction combines active optical elements with copper conductors, resulting in a thinner, lighter cable that maintains signal integrity over the 7.5 m length. The USB-C to Micro-USB B configuration allows connection of Micro-USB devices to USB-C hosts while preserving up to USB 2.0 compatibility for charging and data transfer.

Suitable for

• Connecting Micro-USB B devices (clients) to USB-C hosts or adapters
• Data transfer and firmware updates for media devices and peripherals
• Charging Micro-USB B devices from USB-C power sources within USB 2.0 current limits
• Desktop and AV setups requiring a long, secure cable run

Key specifications

• Connector 1: USB-C (straight male)
• Connector 2: Micro-USB B (straight male) with securing screws
• USB version: USB 2.0 (downwards compatible)
• Cable length: 7.5 m
• Data transfer capability: supports USB 2.0 speeds; cable construction supports high-speed signalling
• Cable jacket colour: black
• Cable construction: active optical / copper hybrid
• Cable diameter: approx. 4.8 mm
• Smallest bending radius: approx. 20 mm
• Operating temperature range: -10 °C to 50 °C
• Output current: up to 900 mA
• Cable jacket material: LSZH (low smoke zero halogen)

How to use

Insert the USB-C connector into the host device or adapter and the Micro-USB B connector into the target device. If the Micro-USB connector has screws, fasten them to secure the connection and prevent accidental disconnection. Ensure both connected devices support the intended data transfer or charging functions; when used with USB 2.0 devices the cable operates within USB 2.0 signalling and current limits.

Recommendations

Avoid sharp bends and tight kinks; respect the minimum bending radius of approximately 20 mm. Use the cable within the specified operating temperature range and avoid exposing the LSZH jacket to direct heat sources. For reliable charging and data transfer, connect to compatible hosts and devices and tighten the Micro-USB screws when a secure connection is required.
