UNIVIEW IPC3614LB-ADF28K-H 4MP IR Bullet IP Camera, 2.8mm Fixed Lens, 30m IR, IP67, IK10, PoE

The UNIVIEW IPC3614LB-ADF28K-H is a high-performance 4MP bullet IP camera designed for outdoor surveillance. Featuring a 1/3" Progressive Scan CMOS sensor, it delivers crisp 2560x1440 resolution at 30fps. Equipped with a 2.8mm fixed lens providing a 104.7° horizontal field of view, this camera is ideal for monitoring wide areas such as parking lots, building perimeters, and entrances. With advanced Ultra 265/H.265 compression, it reduces bandwidth and storage requirements without compromising image quality.

Advantages

The IPC3614LB-ADF28K-H offers exceptional night vision with IR distance up to 30 meters, ensuring 24/7 surveillance. Its IP67 weatherproof and IK10 vandal-resistant housing guarantees reliable operation in harsh environments. Digital WDR and 2D/3D DNR enhance image clarity in challenging lighting conditions. Smart analytics including motion detection, intrusion, and line crossing provide intelligent alerts.

Suitable for

• Outdoor perimeter surveillance
• Parking lots and garages
• Building entrances and corridors
• Retail and commercial premises
• Industrial sites

Key specifications

• Sensor: 1/3" Progressive Scan CMOS
• Max Resolution: 4MP (2560x1440) @ 30fps
• Lens: 2.8mm fixed, F1.6
• Horizontal FOV: 104.7°
• IR Range: Up to 30m
• Video Compression: Ultra 265, H.265, H.264, MJPEG
• Min Illumination: 0.003 Lux (color), 0 Lux (IR on)
• WDR: Digital WDR
• Noise Reduction: 2D/3D DNR
• Network: 1x RJ45 10/100M Ethernet
• Power: 12V DC or PoE (802.3af), max 5.5W
• Local Storage: Micro SD up to 256GB
• Protection: IP67, IK10
• Operating Temp: -30°C to 60°C

Recommendations

For optimal performance, use a PoE switch or injector for simplified installation. Pair with UNIVIEW NVRs for seamless integration and advanced analytics. Ensure the mounting surface is sturdy enough to support the camera's weight.
