UNI-T PRO UT195M SMD Component Tester with Integrated Tweezers

Unlike bulky bench meters or separate tweezer attachments, the UNI-T PRO UT195M combines a precision SMD tester with integrated tweezers in a single pen-type tool. Grab, identify, and measure surface-mount components in one hand, with automatic R/C/D recognition and a 6000-count display. Ideal for electronics repair, prototyping, and quality control, it eliminates guesswork when handling tiny 0402, 0603, or larger SMD parts.

Highlights

• Integrated tweezers with auto identification of resistors, capacitors, and diodes
• 6000-count display with auto range and data hold
• Zener diode testing up to 21 V
• Continuity buzzer and diode test function
• Pen-type form factor for one-handed operation
• Powered by 2 x AAA batteries (included)
• CAT II 36 V safety rating

In daily use

Pick up a suspect SMD resistor, capacitor, or diode directly from the board with the built-in tweezers. The UT195M instantly identifies the component type and displays its value—no need to squint at tiny markings or consult datasheets. The auto-ranging function handles resistances up to 60 MΩ and capacitances up to 100 mF, while the diode test checks forward voltage and the zener function verifies breakdown up to 21 V. A loud continuity buzzer speeds up trace checking, and data hold freezes readings for later reference. Auto power-off preserves battery life between jobs.

Full specifications

• Display counts: 6000
• Measurement type: SMD component tester
• Resistance measurement range: 60 MΩ
• Capacitance measurement range: 100 mF
• DC voltage measurement range: 3.6 V
• Diode test function: Yes
• Continuity test function: Yes (with buzzer)
• Zener diode test voltage: Up to 21 V
• R/C/D auto identification: Yes
• Ranging: Auto range
• Data hold: Yes
• Low battery indicator: Yes
• Auto power off: Yes
• Power supply: 2 x AAA 1.5V batteries
• Safety rating: CAT II 36V
• Form factor: Pen-type with integrated tweezers
• Operating temperature: 0°C to 40°C

Final note

Streamline your SMD workflow with the UNI-T PRO UT195M—precision testing in the palm of your hand.
