TV mount Vision VFM-F27 2.54 m 100 inch Black 90 kg capacity

The Vision VFM-F27 mobile floor stand is a heavy-duty mounting solution for large displays from 55" to 100". Constructed with a premium aluminium column combined with a sturdy steel frame, the stand offers a safe working load of 90 kg and includes a large bottom shelf sized to accommodate Teams and Zoom video bars. Height adjustment is performed with a simple hand crank and the product is supplied with all necessary components.

Advantages

The aluminium column and upgraded components increase rigidity compared with standard models. Four 4" (100 mm) premium casters provide smooth movement over thick carpet and can all be locked for stability. The VESA mount supports up to 800 x 600 mm patterns and includes tilt for reducing overhead reflections. Included accessories—adjustable top camera shelf, large conference bar shelf, mini-PC VESA100 mounting points, cable clips and the option to fit either wheels or feet—make the stand versatile for many AV setups.

Suitable for

• Corporate meeting rooms and boardrooms
• Event centres and AV rental fleets
• Classrooms and lecture theatres
• Shared meeting spaces and huddle rooms with large displays

Key specifications

• Model: Vision VFM-F27 (MPN: VFM-F27)
• Display size compatibility: 55"–100"
• Safe working load (SWL): 90 kg (198 lbs)
• VESA compatibility: up to 800 x 600 mm (supports 200 x 200 mm and larger patterns)
• Height adjustment range: 400 mm (16") via hand crank
• Casters: 4" (100 mm) premium wheels, all lockable
• Conference bar shelf: 800 x 250 mm (W x D)
• Top camera shelf: adjustable height
• Mini PC mount: VESA100 holes and M4 standoffs
• Cable management: adhesive cable clips included
• Conversion options: removable wheels with included feet; two wall brackets for wall-fixing configuration

How to use

Mount the display to the VESA-compatible bracket, ensuring the display weight and VESA pattern do not exceed the specified limits. Use the side crank handle to raise or lower the screen up to 400 mm (16") to the desired height. Fit the conference bar on the lower shelf and the camera on the top shelf; both shelves can be adjusted for optimal positioning. Route cables along the column using the supplied adhesive clips. For a stationary installation, replace the wheels with the included feet or install the supplied wall brackets as required.

Recommendations

Check the display's weight and VESA pattern before installation; do not exceed the 90 kg SWL. Lock all four casters when the stand is in use to prevent movement and reduce vibration to attached equipment. Use the provided M4 standoffs and VESA100 holes to secure a mini PC behind the display for a neat setup.
