Thermal Grizzly DeltaMate Fitting HT14, Nickel-plated Brass, G1/4 inch Thread, Push-in Straight Union for 14 mm Tube

The Thermal Grizzly DeltaMate Fitting HT14 is a high-quality push-in straight union designed for reliable connections in pneumatic systems, automation, and industrial machinery. Crafted from nickel-plated brass with a POM release collar and NBR seal, this fitting ensures durability, corrosion resistance, and leak-free performance. Compatible with PA, PU, and PE tubes of 14 mm outer diameter, it supports operating pressures up to 10 bar and temperatures from -20°C to +80°C. The G1/4" thread allows easy integration into existing setups, while the quick connect/disconnect design simplifies installation and maintenance.

Advantages

Nickel-plated brass body offers high corrosion resistance and longevity. The push-in mechanism enables tool-free installation, reducing downtime. Reusable design supports multiple connection cycles without performance loss. RoHS compliant for environmental safety.

Suitable for

• Pneumatic systems and compressed air networks
• Automation and industrial machinery
• Vacuum applications down to -0.95 bar
• Inert gas handling

Key specifications

• Fitting Type: Push-in Straight Union
• Connection: G1/4" thread
• Tube Outer Diameter: 14 mm
• Body Material: Nickel-plated Brass
• Release Collar: POM
• Seal: NBR
• Max. Operating Pressure: 10 bar
• Operating Temperature: -20°C to +80°C
• Compatible Fluids: Compressed air, inert gases, vacuum

Recommendations

For optimal performance, use with PA, PU, or PE tubes of 14 mm OD. Ensure thread sealant is applied to G1/4" connections. Suitable for both new installations and retrofits.
