TELMOR Directional Antenna TT-365-5G/PROTECTED 18 dBi 5 GHz N-Female

The TELMOR Directional Antenna TT-365-5G/PROTECTED is a high-performance outdoor antenna designed for 5 GHz applications, delivering 18 dBi gain with a narrow 20° beamwidth for long-range point-to-point or point-to-multipoint links. Its rugged UV-resistant ABS enclosure and IP67 protection ensure reliable operation in harsh environments.

Advantages

High gain of 18 dBi extends signal range and improves link budget. Narrow 20° beamwidth reduces interference and focuses energy precisely. IP67 rating and wind load resistance up to 200 km/h make it suitable for outdoor installations. Includes U-bolt bracket for easy pole mounting.

Suitable for

• 5 GHz wireless networks (Wi-Fi, point-to-point bridges)
• Outdoor CPE and backhaul links
• ISP and enterprise deployments requiring robust connectivity

Key specifications

• Frequency Range: 5.15 - 5.875 GHz
• Gain: 18 dBi
• Polarization: Vertical
• Horizontal Beamwidth: 20°
• Vertical Beamwidth: 20°
• VSWR: < 1.5
• Impedance: 50 Ohm
• Connector: N-Female
• Front-to-Back Ratio: > 25 dB
• Cross-Polarization Isolation: > 20 dB
• Enclosure: UV-resistant ABS
• Protection Class: IP67
• Mounting: Pole Mount (U-bolt bracket included)
• Operating Temperature: -40°C to +70°C
• Wind Load Resistance: Up to 200 km/h

Recommendations

For optimal performance, pair with a compatible 5 GHz radio and use low-loss coaxial cable. Ensure proper alignment for maximum signal strength.
