Supermicro SuperServer 5019A-FTN4 - Server - Rack-Mountable - 1U - 1 x Intel Atom C3758 - RAM 0 GB - No HDD - AST2400 - GigE - No OS

The Supermicro SuperServer 5019A-FTN4 is a compact, energy-efficient 1U rackmount server designed for high-density deployments. Powered by an Intel Atom C3758 8-core processor and supporting up to 256 GB DDR4 ECC memory, it delivers reliable performance for network appliances, edge computing, and storage applications. With four hot-swap 3.5" SATA3 drive bays, dual M.2 NVMe/SATA slots, and quad 1GbE LAN ports, this server offers flexible storage and networking options. The integrated Aspeed AST2400 BMC provides dedicated IPMI 2.0 with KVM over IP for remote management.

Advantages

Low power consumption with high core density; compact 1U form factor saves rack space; hot-swap drive bays for easy maintenance; comprehensive remote management via IPMI; versatile storage options including M.2 NVMe.

Suitable for

• Network appliances and security appliances
• Edge computing and IoT gateways
• Entry-level storage servers
• Virtualization hosts for light workloads

Key specifications

• Form Factor: 1U Rackmount
• Processor: 1 x Intel Atom C3758 (8 cores, 2.2 GHz)
• Memory: 0 GB installed (4 DIMM slots, max 256 GB DDR4 ECC RDIMM/LRDIMM)
• Storage: 4 x 3.5" hot-swap SATA3 bays (supports 8 x 2.5" with optional kit); 2 x M.2 NVMe/SATA slots
• Network: 4 x 1GbE Intel I350-AM4 + 1 dedicated IPMI LAN
• Graphics: Aspeed AST2400
• Power Supply: 200W AC-DC
• Expansion: 1 x PCI-E 3.0 x4 (in x8 slot)
• USB: 2 x USB 3.0 (rear), 2 x USB 2.0 (front)

Recommendations

This server is ideal for customers seeking a low-power, reliable platform for network functions virtualization (NFV), firewall, or storage applications. Pair with DDR4 ECC memory and SSDs for optimal performance.
