Supermicro RSC-S-6G5 1U LHS Standard Riser Card with One PCI-E 5.0 x16 Slot

The Supermicro RSC-S-6G5 is a high-performance 1U left-hand side (LHS) standard riser card designed for Supermicro server chassis. It provides one PCI Express 5.0 x16 slot, enabling maximum bandwidth for compatible expansion cards such as network adapters, storage controllers, or GPUs. This riser card is passive and requires no additional power, making it easy to integrate into existing systems.

Advantages

Supports PCIe 5.0 for double the bandwidth of PCIe 4.0, ensuring future-proof performance. The LHS orientation fits specific Supermicro 1U chassis layouts, optimizing space and airflow. Passive design reduces power consumption and heat generation.

Suitable for

• Supermicro 1U server chassis requiring a left-hand side riser
• Expanding server capabilities with PCIe 5.0 x16 cards
• Upgrading to high-speed networking or storage solutions

Key specifications

• Product Type: Server Riser Card
• Form Factor: 1U
• PCI Express Generation: 5.0
• PCI Express Lane Configuration: x16
• Number of PCI Express Slots: 1
• Riser Card Orientation: Left Hand Side (LHS)
• Riser Card Type: Standard
• Compatible Motherboard Interface: PCI Express x16
• Supported Expansion Card Type: PCI Express x16
• Supported Expansion Card Profile: Low-Profile
• Compatibility: Supermicro 1U Server Chassis
• Interface: PCI Express
• Connector: PCI Express x16 Edge Connector
• Power Requirement: Passive
• Compliance: RoHS Compliant
• Manufacturer: Supermicro
• Model Number: RSC-S-6G5

Recommendations

Ensure your chassis supports LHS riser cards and that the expansion card is low-profile. This riser is ideal for maximizing PCIe 5.0 performance in dense server environments.
