Supermicro MCP-220-71801-0N NVMe M.2 SSD Mounting Kit for 2.5-inch Hot-Swap Bay

The Supermicro MCP-220-71801-0N NVMe mounting kit is a high-quality metal tray designed to convert a single 2.5-inch hot-swap drive bay into two M.2 NVMe SSD slots. This kit enables efficient server storage expansion by supporting multiple M.2 form factors (2242, 2260, 2280, 22110) and is ideal for data center environments requiring high-speed NVMe storage.

Advantages

Maximizes storage density by utilizing existing 2.5-inch bays, supports the latest NVMe drives for superior performance, and features a tool-less bay insertion design for quick deployment. The robust metal construction ensures durability and reliable operation in demanding server conditions.

Suitable for

• Supermicro 1U/2U/4U servers with 2.5-inch hot-swap drive bays
• Data centers and enterprise environments requiring NVMe storage expansion
• Upgrading server storage without replacing the chassis

Key specifications

• Product Type: NVMe M.2 SSD Mounting Kit
• Compatibility: Supermicro Servers and Workstations
• Supported Drive Form Factor: M.2 2242, 2260, 2280, 22110
• Number of M.2 Drives Supported: 2
• Mounting Location: 2.5-inch Hot-Swap Drive Bay
• Material: Metal
• Color: Black/Silver
• Included Components: M.2 SSD Carrier/Tray, Mounting Screws
• Installation: Tool-less bay insertion, screw mounting for M.2 drives
• RoHS Compliant: Yes

Recommendations

For optimal performance, pair this mounting kit with Supermicro NVMe-compatible motherboards and ensure your server BIOS supports NVMe boot. Always use the included screws to secure M.2 drives properly.
