Stanley FMHT81507-1 FatMax Laser Detector with Clamp for Red Line Lasers

Where most laser detectors merely beep, the Stanley FMHT81507-1 adds dual LCD readouts and selectable accuracy to help you capture a red pulse line up to 50 m away. It pairs instantly with Stanley FatMax line lasers and turns bright-site layout into a one-person job.

Highlights

• Dual front and rear LCD displays with backlight for easy reading from either side
• Two accuracy modes: fine ±1.5 mm and coarse ±3.0 mm at 10 m
• Audible indicator with adjustable volume for noisy environments
• Built-in magnets and rod clamp for flexible mounting
• IP54 dust and splash resistance for tough job sites

In daily use

Clamp the detector onto a grade rod or steel stud, switch on your FatMax pulse laser, and watch the display guide you to the exact beam height. In fine mode you can resolve millimetre-level differences for cabinetry or suspended ceilings; in coarse mode you find the beam faster over long distances. The 9 V battery runs about 20 hours, and the unit shuts itself off after five minutes of inactivity to save power.

Full specifications

• Detection range: up to 50 m (165 ft)
• Accuracy fine mode: ±1.5 mm at 10 m
• Accuracy coarse mode: ±3.0 mm at 10 m
• Compatible laser colour: red
• Compatible laser type: pulse line lasers (e.g., Stanley FatMax)
• Display: front and rear LCD with backlight
• Audio indicator: yes, adjustable volume
• Mounting: built-in magnets and rod clamp
• Power source: 1 x 9 V battery (included)
• Battery life: approximately 20 hours
• IP rating: IP54
• Auto shut-off: after 5 minutes of inactivity
• Operating temperature: -10 °C to 50 °C
• Housing material: durable plastic with rubber overmold
• Included accessories: rod clamp

Final note

For anyone running red FatMax lasers on bright exteriors or long interior shots, this detector is the missing half of the system — accurate, readable, and built to survive the van ride.
