SpeaKa Professional SP-SWAP-500 2-Port HDMI KVM Matrix Switch with Audio, 4K UHD, USB 2.0 Hub, Metal, Black SP-13904372

Unlike ordinary KVM switches that merely toggle between computers, the SP-SWAP-500 acts as a true matrix, letting you route any of two HDMI sources to a single display while independently switching USB peripherals and audio. This dual-PC control hub eliminates the need for multiple keyboards, mice, and monitors, streamlining your workspace without compromising on 4K clarity.

Highlights

• 2-computer, 1-console HDMI KVM matrix switch with audio support
• Supports resolutions up to 3840 x 2160 (4K UHD) at 30 Hz
• HDCP 1.4 compliant for protected content playback
• Built-in 2-port USB 2.0 hub for keyboard, mouse, and peripherals
• Switching via front-panel push buttons or keyboard hotkeys
• USB-powered – no external power adapter required
• Durable metal housing in black
• LED indicators for active port status

In daily use

Connect two HDMI-equipped computers to the switch using the included USB and HDMI cables, then attach a single monitor, keyboard, mouse, and speakers. Press the front button or use a hotkey to instantly switch control between systems. The matrix architecture allows independent routing of video, USB, and audio, so you can, for example, view PC 1 while typing on PC 2. The 4K resolution support keeps images sharp on high-resolution displays, and HDCP 1.4 ensures compatibility with streaming services and Blu-ray content. The metal chassis dissipates heat effectively and withstands frequent handling, while USB power means one less cable cluttering your desk.

Full specifications

• KVM ports (computers): 2
• Console ports (monitors): 1
• Video input interface: 2x HDMI
• Video output interface: 1x HDMI
• USB input interface (computers): 2x USB-B
• USB console interface (peripherals): 2x USB-A (USB 2.0)
• Audio input interface (computers): 2x 3.5 mm jack
• Audio output interface (console): 1x 3.5 mm jack
• Maximum resolution: 3840 x 2160 (4K UHD)
• Maximum refresh rate at 4K: 30 Hz
• HDCP support: HDCP 1.4
• Switching methods: push button, hotkey
• USB hub: 2-port USB 2.0
• Power supply: USB powered (5V DC)
• Housing material: metal
• Colour: black
• Operating system compatibility: Windows, macOS, Linux
• LED indicators: yes (active port)

Final note

The SP-SWAP-500 is a compact, reliable solution for professionals who need to manage two computers with one set of peripherals. Its matrix switching, 4K support, and robust metal build make it a smart investment for any dual-PC setup.
