Socket outlet Busch-Jaeger 2CKA006220A0017 230 V 4 A IP20 Black/Grey 71x71x45 mm

Socket outlet Busch-Jaeger model 2CKA006220A0017 for 230 V mains with rated current 4 A, finished in black and grey. The compact device (71 × 71 × 45 mm) is designed for indoor use with IP20 protection and is suitable for installation in standard mounting locations. The product supports connection to building bus systems via the supplied bus terminal and is compatible with associated rocker switches listed by the manufacturer.

Advantages

The outlet combines a low-current 4 A rating with compact dimensions for space-saving installation. It includes a bus connection via the supplied bus terminal, supports later configuration via a web interface for grouping and scene settings, and is preconfigured for direct operation without additional programming. The black/grey design suits a range of interior styles and the IP20 rating indicates suitability for dry indoor environments.

Suitable for

Key specifications

How to use

Mount the socket outlet into a standard flush-mounted box and connect the 230 V supply according to local electrical regulations. Attach the bus connection using the supplied bus terminal. For mechanical connection to rocker switches, use compatible Busch-Jaeger models (6230-10-xxx to 6234-10-xxx). After wiring, the device is ready for use in its preconfigured state; further configuration (groups, scenes) can be performed through the web interface if required.

Recommendations

Ensure a clear spatial separation between the bus wiring and the 127 V/230 V mains wiring when installing in a flush-mounted box. If the minimum separation cannot be maintained, use separate electronic boxes or insulating sleeves to prevent interference and maintain safety.
