SMART-HORIZON Directional Panel Antenna 5.1-5.9 GHz 20 dBi Dual-Polarized N-Female Outdoor

When omnidirectional antennas drown in interference, the SMART-HORIZON cuts through with a focused 20 dBi beam and dual-polarized performance. Built for long-range 5 GHz links, this directional panel antenna concentrates RF energy into a tight 18° pattern, delivering stable point-to-point and point-to-multipoint connectivity over several kilometers. The rugged aluminum body with UV-resistant ABS radome shrugs off harsh weather, while the included mast clamp fits poles from 30 to 50 mm. With a front-to-back ratio above 30 dB, it rejects unwanted signals from behind, keeping your link clean even in crowded spectrum.

Highlights

• High 20 dBi gain for extended range and stronger signal reception
• Dual polarization (vertical and horizontal) for MIMO and polarization diversity
• Narrow 18° horizontal and vertical beamwidth reduces interference
• Durable aluminum body with UV-resistant ABS radome
• Includes mast clamp for poles Ø 30–50 mm
• Wind resistance up to 200 km/h
• Wide operating temperature range: -40°C to +70°C
• DC grounded for lightning protection

In daily use

Mount the SMART-HORIZON on a mast or pole using the included clamp, then connect two N-female ports to your radio or access point with low-loss coaxial cables. The dual-polarized feed allows simultaneous vertical and horizontal transmission, which is essential for 2x2 MIMO systems and helps maintain high data rates even in multipath environments. With a front-to-back ratio greater than 30 dB, the antenna rejects signals from behind, reducing noise and improving link reliability.

Full specifications

• Antenna Type: Directional Panel Antenna
• Frequency Range: 5.1 - 5.9 GHz
• Gain: 20 dBi
• Polarization: Dual (Vertical and Horizontal)
• VSWR: < 1.5
• Horizontal Beamwidth: 18°
• Vertical Beamwidth: 18°
• Front-to-Back Ratio: > 30 dB
• Impedance: 50 Ohm
• Connector Type: 2x N-Female
• Material: Aluminum, UV Resistant Plastic
• Mounting Type: Mast Clamp (included)
• Mast Diameter Support: Ø 30-50 mm
• Wind Resistance: Up to 200 km/h
• Operating Temperature: -40°C to +70°C
• Application: Point-to-Point, Point-to-Multipoint, Wi-Fi 5GHz
• DC Grounded: Yes
• Radome Material: UV Resistant ABS

Final note

For network engineers and WISPs who demand reliable long-haul 5 GHz links, the SMART-HORIZON delivers focused gain, dual polarization, and weatherproof durability in one compact package.
