SILVERSTONE TECHNOLOGY SST-NT09-AM5 Low Profile CPU Cooler, 92mm Fan, 2 Heat Pipes, AMD AM5, Black

The SILVERSTONE TECHNOLOGY SST-NT09-AM5 is a low-profile CPU cooler designed specifically for AMD AM5 sockets. With a compact 70mm height, it fits easily into small form factor cases while providing efficient cooling for processors up to 95W TDP. The cooler features a 92mm fan with PWM control, two 6mm copper heat pipes, and an aluminum fin array with copper base for optimal heat dissipation.

Advantages

Ultra-low profile design (70mm) ensures compatibility with space-constrained builds. The 92mm fan delivers high airflow (47.5 CFM) and static pressure (2.5 mmH2O) while maintaining low noise levels (18.5-35.8 dBA). PWM support allows precise fan speed control from 800 to 3000 RPM. Long life sleeve bearing ensures durability.

Suitable for

• Small form factor (SFF) PC builds
• HTPC and media center systems
• Compact gaming rigs with AMD AM5 processors
• Office and productivity workstations requiring quiet operation

Key specifications

• Cooler Type: Low Profile CPU Cooler
• Socket Compatibility: AMD AM5
• Heat Sink Material: Copper Base, Aluminum Fins
• Heat Pipes: 2 x Ø6mm Copper Heat Pipes
• Fan Diameter: 92 mm
• Fan Thickness: 15 mm
• Fan Speed: 800 - 3000 RPM
• Max Airflow: 47.5 CFM
• Max Static Pressure: 2.5 mmH2O
• Noise Level: 18.5 - 35.8 dBA
• Bearing Type: Long Life Sleeve Bearing
• Fan Connector: 4-pin PWM
• Rated Voltage: 12V DC
• Rated Current: 0.2A
• Power Consumption: 2.4W
• TDP Support: 95W

Recommendations

For optimal performance, ensure your case has adequate airflow. The included mounting kit simplifies installation on AM5 motherboards. Pair with a low-profile RAM kit to avoid clearance issues.
