Siemens SIMATIC S7-1200 G2 CPU 1212FC DC/DC/DC 8DI/6DO (6ES7212-1AF50-0XB0)

The Siemens SIMATIC S7-1200 G2 CPU 1212FC is a compact fail-safe CPU designed for the SIMATIC S7-1200 controller family. It offers a powerful combination of performance, safety, and flexibility for a wide range of automation applications. With integrated PROFINET interfaces and support for safety functions, this CPU is ideal for machine and plant engineering where both standard and safety-related tasks need to be handled efficiently.

Advantages

Integrated safety functions reduce the need for additional safety modules, saving space and cost. The compact design allows for flexible mounting on DIN rails, and the DC/DC/DC configuration ensures reliable operation in industrial environments. With 8 digital inputs and 6 digital outputs, it provides sufficient I/O for many applications, and the expandability via signal boards and modules allows for customization.

Suitable for

• Machine building
• Plant engineering
• Automation systems requiring fail-safe operation
• Applications with moderate I/O requirements

Key specifications

• Product Type: Compact CPU
• Series: SIMATIC S7-1200
• CPU Model: 1212FC
• Supply Voltage: 24 V DC
• Digital Inputs: 8
• Digital Outputs: 6 (Transistor)
• Communication Interface: 2 x PROFINET (RJ45)
• Program Memory: 30 KB
• Data Memory: 10 KB
• Safety Integrated: Yes
• Mounting: DIN rail
• Operating Temperature: 0 to 50 °C

Recommendations

For optimal performance, use this CPU with Siemens TIA Portal for programming and configuration. Ensure proper ventilation and mounting orientation to maintain operating temperature limits.
