Siemens SIMATIC ET 200SP Digital Output Module 4x24VDC/2A 6ES7136-6RA00-0BF0

The Siemens SIMATIC ET 200SP Digital Output Module 6ES7136-6RA00-0BF0 is a high-feature electronic module designed for industrial automation. It provides 4 digital outputs with 24V DC and 2A per channel, featuring PNP switching and comprehensive diagnostics. This module is part of the SIMATIC ET 200SP series and is compatible with Type A0 BaseUnits.

Advantages

High reliability with short-circuit, overload, and reverse polarity protection. Channel and group diagnostics enable quick fault detection. Compact design saves space on the DIN rail. Firmware update capability ensures future-proof operation.

Suitable for

• Industrial automation and control systems
• PLC-based applications requiring digital output control
• Integration into SIMATIC ET 200SP distributed I/O systems

Key specifications

• Brand: Siemens
• Model: 6ES7136-6RA00-0BF0
• MPN: 6ES71366RA000BF0
• EAN: 4047623402596
• Module Type: Digital Output Module
• Series: SIMATIC ET 200SP
• Number of Digital Outputs: 4
• Output Voltage: 24V DC
• Output Current per Channel: 2 A
• Output Switching Type: Source output (PNP, P-switching)
• Feature Level: High Feature
• Compatible BaseUnit: Type A0
• Color Code: A0
• Diagnostics: Channel diagnostics, Group diagnostics, Short-circuit, Wire break, Supply voltage monitoring
• Protection Features: Short-circuit protection, Overload protection, Reverse polarity protection
• Isolation: Yes, between channels and backplane bus
• Power Loss: Max. 1.5 W
• Operating Temperature: -30 to +60 °C
• Mounting Type: On BaseUnit
• Configuration Software: TIA Portal
• Firmware Update Capability: Yes

Recommendations

For optimal performance, use with Siemens SIMATIC ET 200SP BaseUnit Type A0 and configure via TIA Portal. Ensure proper supply voltage and observe derating at high temperatures.
