SHINING 3D Cast Wax Resin DC12 1kg - Purple, for Jewelry Investment Casting

The SHINING 3D Cast Wax Resin DC12 is a high-performance castable wax resin specifically formulated for jewelry investment casting. With a net weight of 1 kg, this resin delivers clean burnout with minimal ash content (<0.1%), ensuring precise and detailed castings. Its purple color provides excellent contrast during printing and post-processing.

Advantages

Low ash content ensures residue-free burnout, high detail resolution for intricate jewelry designs, smooth surface finish reducing post-processing time, and compatibility with DLP/LCD 3D printers operating at 385-405 nm wavelength.

Suitable for

• Jewelry investment casting
• Dental cast models
• Artistic and decorative metal castings

Key specifications

• Resin Type: Castable Wax Resin
• Color: Purple
• Net Weight: 1 kg
• Viscosity: 100-200 mPa·s (at 25°C)
• Density: 1.05-1.15 g/cm³ (at 25°C)
• Hardness (Post-Cured): 70-80 Shore D
• Tensile Strength (Post-Cured): 20-30 MPa
• Elongation at Break (Post-Cured): 5-10%
• Ash Content: <0.1%
• Shrinkage: <1%
• Burnout Characteristics: Clean, residue-free
• Post-Processing: IPA Wash, UV Post-Cure
• Storage: Cool, dry place, away from direct sunlight

Recommendations

For optimal results, ensure proper UV post-curing and follow manufacturer guidelines for burnout cycles. Store in a cool, dark environment to maintain resin properties.
