Server Supermicro SuperChassis 813MF2TQC-505CB

The Server Supermicro SuperChassis 813MF2TQC-505CB is a 1U rack chassis in black designed for compact, high-density server deployments. It accepts 3.5" hard drives and includes an integrated 500 W power supply with wide-range AC input (100–240 V, 50–60 Hz). With a width of 437 mm, depth of 507 mm and height of 43 mm, the chassis is sized to fit standard 19-inch racks while conserving rack unit space for versatile data center and edge installations.

Advantages

The chassis combines a slim 1U profile with support for 3.5" HDDs, enabling higher storage capacity per rack unit compared with typical 2.5"-only designs. The built-in 500 W power supply offers consistent power delivery across a broad input voltage range, supporting international deployments. The black finish and standard rack dimensions simplify integration into existing rack systems and cable management layouts.

Suitable for

• Enterprise and small data center rack servers where space efficiency is important
• Storage-dense applications that require 3.5" HDD support
• Edge computing or branch office installations with standard 19" racks
• Systems requiring a compact 1U chassis with a built-in 500 W power supply

Key specifications

• Form factor: 1U rack chassis
• Supported drive size: 3.5" HDD bays
• Power supply: 500 W integrated unit
• AC input voltage: 100–240 V
• AC input frequency: 50–60 Hz
• Dimensions (W × D × H): 437 mm × 507 mm × 43 mm
• Color: Black

How to use

Mount the chassis into a standard 19" rack using the appropriate rail or mounting kit and secure it according to rack manufacturer instructions. Install compatible 3.5" hard drives into the drive bays, connect internal data and power cables to the server motherboard or backplane, and verify the power supply connections. Ensure the AC input matches the available outlet voltage within the 100–240 V range and use proper grounding. After installation, power on the unit and monitor fan and power indicators to confirm normal operation.

Recommendations

For reliable operation, use quality 3.5" enterprise HDDs and keep adequate airflow in the rack: maintain recommended clearance at the front and rear, follow the rack's cooling plan, and avoid blocking ventilation. Verify that the 500 W power capacity meets the installed system components' peak consumption and consider UPS protection for uninterrupted operation.
